overridden by a Preferences sheet in the active game profile. Likewise, each mode sheet can modify preferences
that are active only on that sheet. Every time the configuration changes in the Quadstick, the prefs.csv file is
read, then any values in a Preference sheet in the active game configuration file are read, then the any individual
preferences in the active mode sheet are applied. A typical use-case could be special modes sheets, like a driving
mode, or a sniper mode, where the joystick sensitivity may be reduced to make steering or aiming easier.
Preferences
prefs.csv
Preference
joystick_deflection_minimum
joystick_deflection_maximum 30
deflection_multiplier_up
deflection_multiplier_down
deflection_multiplier_left
deflection_multiplier_right
joystick_dead_zone_shape
anti_dead_zone
joystick_warning
joystick_alarm
usb_1_multiplier_up
usb_1_multiplier_down
usb_1_multiplier_left
usb_1_multiplier_right
usb_2_multiplier_up
usb_2_multiplier_down
usb_2_multiplier_left
usb_2_multiplier_right
Can be set in prefs.csv or Preferences page in game csv file
Can be changed with voice command, or file
Value Units Can be changed on Mode sheet, Command or file
9 percent Defines center dead zone. Percent of physical movement
percent Defines physical deflection scaled to 100% Signal
140 percent Adjusts joystick deflection value in the UP direction
130 percent Adjusts joystick deflection value in the DOWN direction
100 percent Adjusts joystick deflection value in the LEFT direction
100 percent Adjusts joystick deflection value in the RIGHT direction
1 0=Square, 1=Circle
0 percent Counteracts the dead zone built into the Game Console's joystick s
400 percent Joystick position beyond full scale that will flash the leds
500 percent Joysitck position beyond full scale that will buzz the speaker
100 percent Adjusts a USB input sensitivity in one direction
100 percent Adjusts a USB input sensitivity in one direction
100 percent Adjusts a USB input sensitivity in one direction
100 percent Adjusts a USB input sensitivity in one direction
100 percent Adjusts a USB input sensitivity in one direction
100 percent Adjusts a USB input sensitivity in one direction
100 percent Adjusts a USB input sensitivity in one direction
100 percent Adjusts a USB input sensitivity in one direction
