The following table contains the name of all the Joystick Zones input signals, with a brief description and if the
adjustable delay timer is used to detect the input.
Input Name
left
right
up
down
N
NE
E
SE
S
SW
W
NW
N_inner
NE_inner
E_inner
SE_inner
S_inner
SW_inner
W_inner
NW_inner
Table 1: Joystick Inputs
Sixteen discrete signals can be produced from the joystick using the eight compass directions and the inner/outer
rings, plus using the Bite sensor like a Shift key, brings the total to thirty-two.
The deflection ring thresholds and overall sensitivity of the joystick are adjustable by the user. If the inner ring
zones are not used in a specific profile, the audio tones are suppressed.
Description
Joystick Left Analog value
Joystick Right Analog value
Joystick Up Analog value
Joystick Down Analog value
Joystick Outer ring North zone
Joystick Outer ring North East zone
Joystick Outer ring East zone
Joystick Outer ring South East zone
Joystick Outer ring South zone
Joystick Outer ring South West zone
Joystick Outer ring West zone
Joystick Outer ring North West zone
Joystick Inner ring North zone
Joystick Inner ring North East zone
Joystick Inner ring East zone
Joystick Inner ring South East zone
Joystick Inner ring South zone
Joystick Inner ring South West zone
Joystick Inner ring West zone
Joystick Inner ring North West zone
21
Delay
instant
instant
instant
instant
instant
instant
instant
instant
instant
instant
instant
instant
delay
delay
delay
delay
delay
delay
delay
delay
