INSTALLATION & USER MANUAL
E l e m e n t 4 M o d o r e 7 5 H
P L E A S E L E AV E T H E S E I N ST R U CT I O N S B E H I N D W I T H T H E D E V I C E

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Modore 75H and is the answer not in the manual?

Questions and answers

Related Manuals for Element4 Modore 75H

Summary of Contents for Element4 Modore 75H

  • Page 1 INSTALLATION & USER MANUAL E l e m e n t 4 M o d o r e 7 5 H P L E A S E L E AV E T H E S E I N ST R U CT I O N S B E H I N D W I T H T H E D E V I C E...
  • Page 2 I N STA L L AT I O N M A N UA L...
  • Page 3 I N STA L L AT I O N M A N UA L T H I S P R O D U CT I S N OT S U I T E D FO R US E A S A P R I M A I RY H E AT S O U R C E .
  • Page 4 I N STA L L AT I O N M A N UA L...

  • Page 5: Table Of Contents

    7.2 Calculate chimney 8 Installation check and first usage 8.1 Renovation/new construction 9 Elektrical circuit 9.1 Domotica 9.2 Element4 ProControl App. 10 Maintenance instruction 10.1 Maintenance in the combustion chamber 10.2 Cleaning the glass 11 Decoration arrangement 12 User Instruction 12.1 Hand over to the customer...

  • Page 6: Ce Statement

    This declaration loses its validity when changes to the device are is broken. The flue gasses can get into the installation room. The made without the written permission by Element4. You can ask settings and construction of the device must not be changed! for a copy of the test certificates of all models via our general e-mail adress, which is found on the back of this manual.

  • Page 7: Warranty

    In case the installer is not able to fix the problem himself, a request can be made to Element4 to do it for him, as long as the service can be done within the borders of the Benelux.

  • Page 8: Remote Control With Full Electronic Ignition

    I N STA L L AT I O N M A N UA L 4 Remote control with full electronic ignition The unit is operated using a remote control (fig. 4-1). The ignition, regulating the flame height and switching off is done using the remote control, operating a receiver (fig.

  • Page 9: Installation Preparation And - Instruction

    Figure 5-1) under 85 C. Use the ventilation grate (CVRE4) and service hatch (BDLE4) by Element4. See the measurements in appendix I. 5.5 Requirements flue and wall terminals More on chimney construction in the next chapter. The European CE-marking for the device is only applicable to...

  • Page 10: Fire Safe Installation

    I N STA L L AT I O N M A N UA L 6 Fire safe installation To install a gas fireplace as safely as possible, several installation preparations need to be made. This overview can be used to assure the fire safety of a conversion of a fireplace.
  • Page 11 I N STA L L AT I O N M A N UA L Assembly regulations (Figure 6-3 and 6-4) Covering of Flammable wall non-flammable • Load-bearing walls and ceilings must be covered in a material Non-flammable protective fire resistant plate. insulation 25mm Air cavity 50mm Never use flammable materials around the fireplace or cove.

  • Page 12: Attention Points Gas Flue

    I N STA L L AT I O N M A N UA L 7 Attention points gas flue 8 Installation check and first usage 8.1 Renovation/new construction To guarantee the fire safety regarding you flue gas configuration a casing is necessary. For this case non-combustible materials should be used.

  • Page 13: Elektrical Circuit

    ProControl manual The app has a user friendly, interactive layout and the design is adjusted for Element4 devices. Up to eight devices can be used Should any problems occur you can always check appendix B. with one app, in the situation that multiple fire are installed in the same location.

  • Page 14: Maintenance Instruction

    Use cleaning supplies qualified by Element4. • When you clean your Anti-Reflective glass, make sure you use this with the special Element4 cleaner, which is available only via Element4. • Use only a microfibre cloth. Other materials such as kitchen towels, steel wool etcetera can cause scratches or damage the coating on the glass.
  • Page 15 I N STA L L AT I O N M A N UA L Afbeelding 10-2: Removing side trims Afbeelding 10-5: Put on the suction cups Afbeelding 10-3: Removing lower trim Afbeelding 10-6: Removing glass Afbeelding 10-4: Removing cords...

  • Page 16: Decoration Arrangement

    Ensure that the grate is sitting firmly in the base of the fire An elaborate instruction is available via Element4 or on the log box, with the long slot in the centre of the Grate aligning with set instruction that are supplied with every device on purchase.

  • Page 17: User Instruction

    Only use a neutral cleaning product guarantee (neither acidic nor alkaline), such as Element4 window cleaner (Item No. 4500926). The cleaning agents that you normally use 12.1 Hand over to the customer should therefore not be used with an anti-reflective glass.

  • Page 18: Warranty Conditions

    If the installer himself can not rectify the malfunction, he can request Element4 BV to do so, if this is within the boundaries of the Benelux. Only after prior consultation can the entire device or parts of it be sent for inspection or repair.
  • Page 19 I N STA L L AT I O N M A N UA L...

  • Page 20: A First Aid For Malfunction

    A P P E N D I C E S A First aid for malfunction Below you will find an overview of the possible cause and solution in the event of a failure. Problem Possible Cause Solution No transmission 1 Batteries in the receiver empty Replace the batteries (4x 1.5V AA) (motor will not 2 Batteries hand remote empty...
  • Page 21 A P P E N D I C E S 4,5 mV 4,5 mV Figure A-5: interrupter Figure A-1: Bend pin Figure A-4: Testpoint A Figure A-2: Antenna Figure A-6: Wiring receiver Figure A-7: Pilot set Figure A-3: Torx screw...
  • Page 22 A P P E N D I C E S Problem Possible Cause Solution The pilot light goes 1 Insufficient voltage across the thermocouple or Place the measuring pins of the multimeter on the ground and on but goes out too much resistance in the thermocouple circuit black cable of the breaker.
  • Page 23 A P P E N D I C E S Figure A-8: Second thermocouple Figure A-12: “Doubble plus”-button on the remote Figure A-9: Button A on “On” Figure A-13: SI-entrance Figure A-10: RESET-button Figure A-11: Aux-position receiver Figure A-14: Domotica system...

  • Page 24: B Errors Codes Procontrol App

    A P P E N D I C E S B Errors codes Procontrol App Error Message in App Description Possible cause code Contact service 5 sec beep van de ontvanger. • No engine end stop Geen reactie van ontvanger, en geen ontsteking. •...
  • Page 25 A P P E N D I C E S Error App Message Time Description Possible Cause code 4 sec. 5 seconds beep from the receiver. No engine end stop No response from receiver, and no Wiring motor ignition. Microswitch Knob B 4 sec.

  • Page 26: C Faults And Error Codes In The Remote

    A P P E N D I C E S C Faults and error codes in the remote This appendix can be consulted when error messages occur in the application for smartphone and tablet. F41 error This message will appear if there is no or bad Wi-Fi reception, this can be between app and router or Wi-Fi box and router By closing the App and opening it again, this is solved in most cases.

  • Page 27: D Location Terminal

    A P P E N D I C E S D Location terminal “Distance” = minimum distance required to position the exhaust in order to prevent adverse effects in relation to; Position terminal dist. A ventilation opening of a used room, toilet or bathroom (mm) Supply of heated air when the supply flows through a used Directly below an opening, ventilation stone,...

  • Page 28: E General Rules For Flue Gas Extraction

    A P P E N D I C E S E General rules for flue gas extraction E.1 Power-Fan For flue configurations that do not function on natural draft, the Power-Fan can be used. A maximum discharge length of 36 meters horizontally and vertically together is then possible.

  • Page 29: F Calculation Table Flue Gas Limiter

    A P P E N D I C E S F Calculation table flue gas limiter The calculation table shows when you need to place a flue gas limiter Result Action No ristrictor required Position the resitrictor No good operation guaranteed * * Perhaps the powerfan is a good solution here.

  • Page 30: G Technical Data

    A P P E N D I C E S G Technical data The dataplate specifies for which type of gas, gas pressure and for which country this appliance is intended. The nameplate is attached to a chain. It must remain attached to the chain. Note: Check whether the appliance is suitable for the gas type and gas pressure on site.

  • Page 31: H Ecodesign

    The ecolabel shows which category the fireplace belongs to. H.1 Ecolabels The ecolabels for the different types of gas are indicated below, respectively G20, G25 and G30. Bioptica Modore 75H | G20 Modore 75H | G25 Modore 75H | G30...

  • Page 32: I Dimensional Drawings

    A P P E N D I C E S I Dimensional drawings On this page and the following ones you will find dimensional drawings of the Cupido models and accessories with some of the important dimensions that you have to take into account when installing and installing your fireplace.
  • Page 33 A P P E N D I C E S Afbeelding I-2: Technical drawing Modore 75H...
  • Page 34 A P P E N D I C E S...
  • Page 35 A P P E N D I C E S...
  • Page 36 E L E M E N T 4 B .V. Paxtonstraat 23 8013 RP Zwolle The Netherlands Info@element4.nl www.element4-fires.com A P R I L 2 0 1 8...
