I N S TA L L AT I O N M A N U A L
I N S TA L L AT I O N M A N U A L
M O D O R E - A N D T E N O R E 2 4 0
Please leave these instructions behind with the device

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MODORE 240 and is the answer not in the manual?

Questions and answers

Related Manuals for Element4 MODORE 240

Summary of Contents for Element4 MODORE 240

  • Page 1 I N S TA L L AT I O N M A N U A L I N S TA L L AT I O N M A N U A L M O D O R E - A N D T E N O R E 2 4 0 Please leave these instructions behind with the device...
  • Page 2 I N S T A L L A T I O N M A N U A L Do not use this product as a primary heat source...

  • Page 3: Table Of Contents

    ELEMENT4 PROCONTROL APP� � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � �...
  • Page 4 I N S T A L L A T I O N M A N U A L MAINTENANCE INSTRUCTION � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � �14 9�1 MAINTENANCE IN THE COMBUSTION CHAMBER �...

  • Page 5: Ce Statement

    CHAPTER 10 CHAPTER 10 " for an without the written permission by Element4. You can ask for a copy of instruction on how to arrange the decoration properly. the test certificates of all models via our general e-mail adress, which is •...

  • Page 6: Warranty

    In case the installer is not able to fix the problem himself, a request can be made to Element4 to do it for him, as long as the service can be done within the borders of the Benelux.

  • Page 7: Remote Control With Full Electronic Ignition

    REMOTE CONTROL WITH FULL ELECTRONIC IGNITION 4�2 IGNITING THE PILOT LIGHT Figure 4.1 The unit is operated using a remote control ( ) or the Element4 Figure 4.3 Check that the control knob (A) is in the ON position( ). Press Figure 4.2...

  • Page 8: Installation Preparation And - Instruction

    The flue system must be constructed from the appliance upwards, with needs no additional ventilation. However an adequate supply of all joints being fully locked and sealed using the Element4 specified fresh air to maintain temperatures and a comfortable environment is parts.

  • Page 9: Fire Safe Installation

    I N S T A L L A T I O N M A N U A L | Chapter 6 FIRE SAFE INSTALLATION To install a gas fireplace as safely as possible, several installation preparations need to be made. This overview can be used to assure the fire safety of a conversion of a fireplace.
  • Page 10 I N S T A L L A T I O N M A N U A L | Chapter 6 Figure 6.1 | C11: Flue situation Non-Flammable materials Figure 6.3 | C11: Flue situation Flammable materials Figure 6.2 | C31: Flue situation Non-Flammable materials Figure 6.4 | C31: Flue situation Flammable materials...

  • Page 11: Other Rules Regarding Heat In Your Installation

    6�3�4 OUTDOOR INSTALLATION This appliance is meant for indoor use. In the case that an Element4 6�3�2 CONVECTION appliance is to be installed as part of an indoor outdoor construction,...

  • Page 12: Attention Points Flue Gas Extraction

    I N S T A L L A T I O N M A N U A L | Chapter 7 ATTENTION POINTS FLUE GAS EXTRACTION 7�3 BENDS To guarantee the fire safety regarding you flue gas configuration a casing Be aware of the bends in your flue.

  • Page 13: Calculate Flue Length

    For flue configurations that do not function on natural draft, the PowerFan can be used. For extensive installation instructions and the operation of the PowerFan we refer to the manual of the PowerFan on the Element4 website or via your dealer.

  • Page 14: Electrical Circuit

    The app has a user friendly, interactive layout and the design is adjusted Necessities for the installation of the ProControl: for Element4 devices. Up to eight devices can be used with one app, in • 220 volt electricty near the fire the situation that multiple fire are installed in the same location.

  • Page 15: Maintenance Instruction

    No these trims must be removed, before the glass can be removed. Please liability can be accepted by Element4 for injury caused by burning or follow these steps: scolding by a hot appliance.
  • Page 16 I N S T A L L A T I O N M A N U A L | Chapter 9 Figure 9.2 | Figure 9.5 | Remove side trims Put on suction cup Figure 9.3 | Remove bottom trim Figure 9.6 | Remove side glasses Figure 9.4 |...

  • Page 17: 9�2 Servicing The Burner

    9�2�3 THERMOCOUPLES The Element4 fireplaces have two thermocouples; one next to the pilot and one opposite the pilot side of the burner. The completeness and operation of both must be checked. A qualified installer must confirm that both thermocouples are in place and undamaged.

  • Page 18: Decorative (Ceramic) Parts

    I N S T A L L A T I O N M A N U A L | Chapter 10 DECORATIVE (CERAMIC) PARTS This appliance is equipped with a ceramic fire bed with heat-resistant An elaborate decoration instruction is found on the sheet in the logset ceramic fibers, or artificial glassy silicate fibers.

  • Page 19: Operating The Fireplace

    I N S T A L L A T I O N M A N U A L | Chapter 11 OPERATING THE FIREPLACE 11�1 BEFORE THE FIRST FIRE Flames and soot During this first fire, examine the flame for appearance and quality. Make sure the cables of the ignition are hanging loosely under the Flames may appear blue at first, but will turn yellow after 15 to 20 device, to ensure a good ignition.

  • Page 20: Atroubleshooter

    I N S T A L L A T I O N M A N U A L | Appendix A TROUBLESHOOTER A�A FIRST AID FOR MALFUNCTION Below you will find an overview of the possible cause and solution in the event of a failure.
  • Page 21 I N S T A L L A T I O N M A N U A L | Appendix A 4,5 mV 4,5 mV Figure A.E | Figure A.A | Figure A.D | Interrupter Bend pin Testpoint Figure A.F | Figure A.B | Wiring receiver Antenna...
  • Page 22 I N S T A L L A T I O N M A N U A L | Appendix A Problem Possible Cause Solution The pilot light goes Insufficient voltage across the thermocouple or Place the measuring pins of the multimeter on the ground and on but goes out too much resistance in the thermocouple circuit black cable of the breaker.
  • Page 23 I N S T A L L A T I O N M A N U A L | Appendix A Figure A.H | Second thermocouple Figure A.L | “Double plus”-button on the remote Figure A.I | Button A on “On” Figure A.J | RESET-button Figure A.M |...

  • Page 24: A�Bnecessary Tools

    If a problem is found, that cannot be solved on site, always contact your Element4 expects are being carried during said services. dealer or directly contact Element4 via our credentials which can be When all these tools are available during service, Element4 guarantees found on the back page of this manual.

  • Page 25: Berrors Codes Procontrol App

    I N S T A L L A T I O N M A N U A L | Appendix B ERRORS CODES PROCONTROL APP B�A MESSAGES SHOWN IN APP Error code Message in App Description Possible cause Contact Service. •...

  • Page 26: B�Bmessages Shown In Remote

    I N S T A L L A T I O N M A N U A L | Appendix B Error code Message in App Description Possible cause Contact Service. • It is not possible to increase flame height •...

  • Page 27: Cfaults And Error Codes In The Remote

    I N S T A L L A T I O N M A N U A L | Appendix C FAULTS AND ERROR CODES IN THE REMOTE Consult this appendix, when error messages occur in the application for smartphone and tablet. C�A F41 ERROR This message will appear if there is no or bad Wi-Fi reception, this can be...

  • Page 28: Dterminal Location

    I N S T A L L A T I O N M A N U A L | Appendix D TERMINAL LOCATION D�B TERMINAL LOCATION WITH HORIZONTAL EXHAUST (C31) D�A TERMINAL LOCATION WITH VERTICAL EXHAUST (C11) Distance Exhaust 1,2 of 3 Position terminal dist.

  • Page 29: Ecalculation Tables Fluegas Restriction

    In the calcualtion table yo ucan see when you need to place a flue gas restrictor The Modore 185, Modore 240 & Tenore 240 need a minimum start length of 1 meter. The Modore 240H, Bidore 240H, Lucius 240H & Tenore 240H need a...

  • Page 30: Ftechnical Data

    I N S T A L L A T I O N M A N U A L | Appendix F TECHNICAL DATA The dataplate specifies for which type of gas, gas pressure and for which country this appliance is intended. The nameplate is attached to a chain. It must remain attached to the chain.

  • Page 31: Gecodesign

    I N S T A L L A T I O N M A N U A L | Appendix G ECODESIGN Since 1 January 2018 every fireplace has been provided with an eco- label which is always supplied with the fireplace. The ecolabel shows which category the fireplace belongs to.

  • Page 32: Hdimensional Drawings

    On this page you will find trhr dimensional drawings of the Modore and Tenore 240 with some of the important dimensions that you have to take into account when installing and installing your fireplace. Figure H.A | Technical drawing of Modore 240...
  • Page 33 I N S T A L L A T I O N M A N U A L | Appendix H Figure H.B | Technical drawing of Tenore 240...
  • Page 34 Design & Assembly by: E L E M E N T 4 B . V. Info@element4.nl www.element4.nl 1 9 / 0 1 / 2 2 RELEASE DATE |...

This manual is also suitable for:

Tenore 240Ovation e4-32
