Chapter Objectives

Standard Features

PowerFlex 40 Standard Configured Drive
Standard Features and Options
This chapter describes the standard features and operation for PowerFlex 40
Standard Configured Drives and associated options.
For information on ...
Standard Features
Enclosure Options
Communication Options
Power Disconnect Options
Operator Device Options
Quick Disconnects
I/O Options
This package integrates the Standard PowerFlex 40 drive. The PowerFlex
40 drive can be used for Volts per hertz or Sensorless Vector applications
and offers an Autotune feature allowing the drive to adapt to individual
motor characteristics.
The PowerFlex 40 is assembled in an enclosure which includes the
following features...
• NEMA/UL Type 4/4X - indoor and outdoor applications other than
(1)
direct sunlight.
• Flange mount drive/external heatsink reducing overall enclosure size.
• Mounting feet - orientation is adjustable per customer requirements.
If required, the drive can be removed from the front of the enclosure for
ease of assembly or repair.
Low cost, highly configurable I/O inputs and/or 0-10V/4-20 mA outputs
that are not used by program standard features and options are available for
customer use.
(1) The enclosure does not normally protect electrical equipment from
condensation, corrosion or contamination, which may occur within the
enclosure or enter via the conduit or unsealed openings. Users must
make adequate provisions to safeguard against such conditions, and
satisfy themselves that the equipment is properly protected. For further
information on criteria associated with NEMA enclosure ratings, refer to
NEMA standards Publication No. 250-1991. When optional Door
Mounted HIM is supplied, enclosure is rated indoor only. See enclosure
options for specific enclosure style quoted.
Chapter
See page ...
1-1
1-2
1-3
1-4
1-9
1-15
1-16
Publication 23B-IN001G
