PowerFlex 40 Standard Configured Drive Standard Features and Options
Local/Off/Remote Selector Switch With One Normally Open Interposing
Relay (Code S21)
This 800F door mounted operator device and interposing relay option is
factory installed and provides a Local/Off/Remote selector switch.
The Local/Off/Remote selector switch will start the drive in Local mode and
stop it in Off mode. In Remote mode, the drive will be stopped and started
from the factory installed CR1 contact which is energized by a customer
supplied and protected 120V AC source. In all cases, the Stop input to the
drive must be present before the drive will start.
In both Local and Remote modes, the speed source is parameter A070
[Preset Freq 0].
Component Specifications
Bulletin 800F IEC style, Internationally rated
Devices
Meet IP65/IP66 and NEMA/UL Type 4/4X/13
UL Listed, CSA Certified
10 amp contacts
Screw terminals, 0.3–3.5 mm
Local/Off/Remote 3 position, Maintained, 2 N.O. contacts
Selector Switch
Interposing Control 1 relay, 10 amp, 120V AC coil, Octal base
Relay
Legend Plate 30 x 50 mm, Black with white lettering
Wiring 0.8 mm
Schematic Figure 2.14 on page 2-15
This option is not compatible with Codes R3, R5, S1, S4, S7, S8, S20 or
S22.
2
(22–12 AWG) maximum
2
(18 AWG), Blue
1-13
Publication 23B-IN001G
