P-4 Overview
Catalog Number
Explanation
1-3 4 5
D
23B –
a b
a
Drive
Code Type
23B PowerFlex 40
b
Voltage Rating
Code Voltage
D 480V ac
c
Amp Rating
480V 60Hz Input
Code Amps
1P4 1.4
2P3 2.3
4P0 4.0
6P0 6.0
010 10.5
012 12
017 17
024 24
d
Enclosure
Code Enclosure
C NEMA/UL Type 4X ‡
D NEMA/UL Type 4 ‡
‡ The design of the PowerFlex 40 Standard
Configured Drive supports indoor and outdoor
applications that are not in direct sunlight.
Publication 23B-IN001G
The PowerFlex 40 Adjustable Frequency AC Standard Configured Drives
catalog numbering scheme is shown below.
6-8 9
4P0 D
c d
Code
1
Fixed Keypad on Drive and LCD
Display with Digital Speed Control
F
This option changes the enclosure rating to
Ph.
indoor only.
3
Code
0
kW (Hp)
0.4 (0.5)
0.75 (1.0)
1.5 (2.0)
2.2 (3.0)
Code
4.0 (5.0)
4
5.5 (7.5)
C
7.5 (10)
D
11 (15)
E
P
Code
N
Code
N
Position
10 11 12
1 0 4
e f g
e
HIM
Interface Module
Fixed Keypad on Drive
HIM on Enclosure Door
(22-HIM-C2S)
f
Emission Class
Rating
Not Filtered
g
Version
Version
RS485 (Standard)
ControlNet
DeviceNet
EtherNet/IP
PROFIBUS DP
h
Rating
Reserved
i
Rating
Reserved
13 14 15
N N –
h i
j
Options
Code Description
DeviceNet Quick Disconnect
-E22
(Bottom)
DeviceNet Quick Disconnect (Left
-E23
Side)
-P3 Motor Circuit Protector
Motor Circuit Protector (Customer
-P3T
wiring into top of device)
-P6 Disconnect Switch - Fused
Disconnect Switch - Fused
-P6T
(Customer wiring into top of device)
DeviceNet I/O (4 In/2 Out) w/Spring
-R3 Return HOA and Power Disconnect
Aux. Contact
-R4 DeviceNet Point I/O w/IB4 (4 Inputs)
-R3 plus 4 I/O Quick Disconnects
-R5
and (1) 24V DC Receptacle
Hand/Off/Auto S.S.
-S1
(Start/Stop/Speed Ref.)
-S4 Auto/Manual S.S. (Speed Ref.)
-S7 Start and Stop P.B.
-S8 Forward/Reverse S.S.
Door Mounted Local Speed Pot (1-
-S18
Turn)
Local/Remote and Local Control
-S20
Off/Run Forward Selector Switches
Local/Off/Remote with 1 N.O.
-S21
Interposing Relay
Spring Return Hand/Off Auto S.S.
-S22
(Start/Stop/Speed Ref.)
-S23 Clear Fault P.B.
16+
P6
j
