Table Of Contents - Aidcall Touchsafe Pro Installation Manual

Section
1
2
3
4
5
5
7
8
9
CONTENTS
1. PRODUCT OVERVIEW
Touchsafe Pro Telecare Receivers (TCR's) provide the interface between Telecare radio devices and the
Nursecall system. A maximum of 32 TCR's can be installed per site.
All TCR's require connection to the Master Panel (ID1) RS485 data bus and a separate 12V DC battery
backed power supply. Multiple PSU's may be required on large installations. Note: if AVI's are installed then
TCR's can be powered from the AVI PSU's provided care is taken not to exceed the PSU rating.
An extensive range of Telecare devices are available to personalize the Nursecall system to specific needs of
staff and patients.
For personal wellbeing there are devices to detect falls, bed occupancy, chair occupancy, wandering,
personal attack and epilepsy.
For environmental monitoring there are devices to detect smoke, heat, gas, carbon monoxide, flood and
high/low room temperatures.
Please contact Aidcall customer services for full details of all devices available and there applications.
CONTENTS
Topic
Product Overview
Important Safety Instructions
Regulatory Information
Maintenance & Care
TCR Features
TCR Installation
TCR Setup
PSU Battery Replacement
Specification
Page
2
3
4
4
5
6
9
10
11
Doc No. FM5565 issue B Page 2
