Aidcall Touchsafe Pro Installation Manual page 12

9. SPECIFICATION
169MHz TCR & Antenna
Safety
EMC
Radio
Materials
Radio Frequency
Radio Range
Max No. TCR's per Site
Data Connection
Power Requirement
Antenna
8 Way DIL Switch
LED Indicators
Enclosure Material
Flammability Rating
Ingress Protection Rating
Dimensions
Weight
Relative Humidity
Operating Humidity Range
Operating Temperature Range
Storage Temperature Range
12V/1A PSU
Manufacturer/Model
Compliance
Type
Input Voltage
Output Voltage/Current
Output Ripple
LED Indicators
Mains Fuse Protection
Load Fuse Protection
Battery Fuse Protection
Enclosure Material
Ingress Protection Rating
Dimensions
Weight
Relative Humidity
Operating Temperature Range
PSU Standby Battery
Manufacturer/Model
Type
Dimensions
Weight
Operating Temperature Range
PSU Mains Lead
Approvals
Cable
Plug
Fuse Type/Rating
Compliance to EN 60950‐1:2006+A12:2011
Compliance to EMC 2004/108/EC
Compliance to EU Directive R&TTE 1999/5/EC
Compliance to EU Directive RoHS 2011/65/EU
169.48125MHz
75 metres typical (indoor)
32
RS485 (115200 Baud)
12V DC 40mA
169MHz ½ Wave Whip Antenna (900mm long) with 1m RG58 Coax & BNC
Switches 1 to 5 = ID, 6, 7 & 8 Not Used
LED1: Green RF RX, LED2: Yellow RS485 RX, LED3: Red RS485 TX
ABS (Light Grey RAL 7035)
UL 94 V‐0
IP60
120mm x 80mm x 55mm (LxWxD)
190 grams (exc Antenna)
Non‐condensing
10% to 90% RH
o o
0 C to 50 C
o o
‐20 C to 60 C
Elmdene G13801N‐A
Low Voltage: 2006/95/EC, EMC 2004/96/EC, WEEE 2002/96/EC
Switch Mode PSU with Electronic Overload Protection
90V to 264V AC 50/60Hz
13.6V to 14.2V DC @ 1A (Nominal 13.8V)
150mV peak to peak
Green = Mains Supply Healthy, Red = Fault (Fuse Blown)
T2.0A 20mm HRC
F1.0A 20mm Glass
F1.0A 20mm Glass
Mild Steel with Hinged Lid (Finish: Stove Enamelled White)
IP40
200mm x 230mm x 80mm (HxWxD)
1.85 kilograms (excluding battery)
95% RH non‐condensing
o o
‐10 C to 40 C
Yuasa NP1.2‐12
12V 1.2Ah Rechargeable Lead Acid
97mm x 48mm x 54.5mm (LxWxH)
580 grams
o o
‐15 C to 50 C
BS 1363/A, VDE and KEMA
2
2 metres long 3 core 0.75 mm (Colour: Black)
BS 1363 moulded non‐rewireable 13A UK Plug
BS 1362 1" 240V AC 5A
Doc No. FM5565 issue B Page 12
