Troubleshooting

6 Troubleshooting

6.1 Warning and Alarm Messages

No. Description
2 Live zero error (LIVE ZERO ERROR)
4 Mains phase loss (MAINS PHASE LOSS)
5 Voltage warning high (DC LINK VOLTAGE
HIGH)
6 Voltage warning low (DC LINK VOLTAGE
LOW)
7 Overvoltage (DC LINK OVERVOLT)
8 Undervoltage (DC LINK UNDERVOLT)
9 Inverter overload (INVERTER TIME)
10 Motor overloaded ( MOTOR, TIME)
11 Motor thermistor (MOTOR THERMISTOR)
12 Current limit (CURRENT LIMIT)
13 Overcurrent (OVERCURRENT)
14 Earth fault (EARTH FAULT)
15 Switch mode fault (SWITCH MODE
FAULT)
16 Short-circuit (CURR. SHORT CIRCUIT)
17 Serial communication timeout (STD BUS
TIMEOUT)
18 HPFB bus timeout (HPFB TIMEOUT)
33 Out of frequency range (OUT FREQ
RNG/ROT LIM)
34 HPFB communication fault (PROFIBUS
OPT. FAULT)
35 Inrush fault (INRUSH FAULT)
36 Overtemperature (OVERTEMPERATURE)
37-45 Internal fault (INTERNAL FAULT)
50 AMT not possible
51 AMT fault re. nameplate data (AMT
TYPE.DATA FAULT)
54 AMT wrong motor (AMT WRONG
MOTOR)
55 AMT timeout (AMT TIMEOUT)
56 AMT warning during AMT (AMT WARN.
DURING AMT)
99 Locked (LOCKED)
Table 6.1 Warning and Alarm Messages
W: Warning
A: Alarm
T: Trip locked
MG28M202
Quick Guide
W A T
X X X Voltage or current signal on terminals 53 or 60 is below 50% of preset
value.
X X X No phase on mains supply side.
X The intermediate circuit voltage exceeds the limit set.
X The intermediate circuit voltage is lower the limit set.
X X X The intermediate voltage exceeds the limit set.
X X X The intermediate voltage is lower than the limit set.
X X The frequency converter is close to tripping due to overload.
X X The motor is too hot due to overload.
X X Either the motor is too hot or the thermistor has been disconnected.
X X Output current is higher than set in par. 221.
X X X The peak current limit has been exceeded.
X X Discharge from output phases to earth.
X X Fault in switch mode power supply.
X X Short-circuit on the motor terminals or in the motor.
X X No serial communication to the frequency converter.
X X No serial communication to the communication option card.
X Output frequency has reached the limit set in either par. 201 or par.
202.
X X Fault only occurs in fieldbus versions. Please see par. 953 in fieldbus
literature.
X X Connected to mains too many times within 1 minute.
X X The upper temperature limit has been exceeded.
X X Contact Danfoss.
X Either R value is outside permitted limits, or motor current is too low
S
on at least one phase, or the motor is too small for AMA.
X Inconsistency between registered motor data.
X AMA has detected a missing motor phase.
X Calculations are taking too long, probably caused by noise on motor
cables.
X Warning is given while AMA is performed.
X See parameter 018 Lock for data changes.
