Control Panel Operations

5.1.4 Display Readout States

In normal operation, one item of operating data can be
displayed continuously at the operator's own choice. Press
the [+/-] keys to select the following options in Display
mode:
•
Output frequency [Hz]
•
Output current [A]
•
Output voltage [V]
•
Intermediate circuit voltage [V]
•
Output power [kW]
•
Scaled output frequency f

5.1.5 Menu Mode

To enter the Menu mode, press [QUICK MENU] and [+] at
the same time.
In Menu mode, most of the frequency converter
parameters can be changed. Scroll through the parameters
using the [+/-] keys. While scrolling in the Menu mode
proceeds, the parameter number flashes.

5.1.6 Quick Menu

Press the [QUICK MENU] key to access the 12 most
important parameters of the frequency converter. After
programming, the frequency converter is in most cases
ready for operation. When the [QUICK MENU] key is
activated in Display mode, the Quick Menu starts. Scroll
through the Quick Menu use the [+/-] keys to scroll
through the Quick Menu. Change data values by first
pressing [CHANGE DATA] and then changing the
parameter value with the [+/-] keys.
The Quick Menu parameters are shown in
chapter 5.4 Parameter List.
MG28M202
Quick Guide
x p008
out
Danfoss A/S © Rev. 2014-03-18 All rights reserved.

5.1.7 Hand Auto

During normal operation the frequency converter is in
Auto mode, where the reference signal is given externally,
analog or digital via the control terminals. However, in
Hand mode, it is possible to give the reference signal
locally via the control panel.
On the control terminals, the following control signals
remain active when Hand mode is activated:
Hand Start (LCP2)
Off Stop (LCP2)
Auto Start (LCP2)
Reset
Coasting Stop Inverse
Reset and Coast Stop Inverse
Thermistor
Precise Stop Inverse
Precise Stop/Start
Switching between Auto- and Hand Mode
By pressing the [Change Data] in Display mode, the display
indicates the mode of the frequency converter.
Scroll up/down to switch to Hand mode. Use [+]/[-] to
change the reference.
NOTICE
Parameter 020 Hand operation may block the choice of
mode.
A change of parameter values is saved automatically after
a mains failure.
If the display shows 3 dots at the right, the parameter
value has more than 3 digits. Press [CHANGE DATA] to see
the value.
Press [QUICK MENU]:
Set the motor parameters that are on the motor
nameplate
•
Motor power [kW] - Parameter 102
•
Motor voltage [V] - Parameter 103
•
Motor frequency [Hz] - Parameter 104
•
Motor current [A] - Parameter 105
•
Rated motor speed - Parameter 106
Quick Stop Inverse
Stop Inverse
Reversing
DC brake inverse
Setup Select LSB
Setup Select MSB
Jog
Stop Comm. Via Serial
Comm.
