  Summary of Contents for AEG BPK722910M

  • Page 1 BPK722910M User Manual Oven USER MANUAL...
  • Page 2: Table Of Contents

    17. WARRANTY ................46 FOR PERFECT RESULTS Thank you for choosing this AEG product. We have created it to give you impeccable performance for many years, with innovative technologies that help make life simpler features you might not find on ordinary appliances. Please spend a few minutes reading to get the very best from it.
  • Page 3: Safety Information

    English 1. SAFETY INFORMATION The symbols you will see in this booklet have these meanings Warning / Caution-Safety information General information and tips Environmental information Subject to change without notice. Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible for any injuries or damages that are the result of incorrect installation or usage.
  • Page 4: Conditions Of Use

    www.aegaustralia.com.au | www.aegnewzealand.co.nz WARNING! The appliance and its accessible parts become hot during use. Care should be taken to avoid touching heating elements. Children shall be kept away unless continuously supervised. • Always use oven gloves to remove or put in accessories or ovenware. •...
  • Page 5 English 3.2 Electrical connection • Open the appliance door carefully. The use of ingredients with alcohol can WARNING! Risk of fire and cause a mixture of alcohol and air. electrical shock. • Do not let sparks or open flames to come in contact with the appliance •...
  • Page 6 www.aegaustralia.com.au | www.aegnewzealand.co.nz 3.4 Care and cleaning • Read carefully all the instructions for Pyrolytic cleaning. WARNING! Risk of injury, fire, or • Keep children away from the appliance damage to the appliance. while the Pyrolytic cleaning is in operation. •...
  • Page 7 English 3.6 Internal light • The type of light bulb or halogen lamp used for this appliance is only for household appliances Do not use it for house lighting. WARNING! Risk of electrical shock. • Before replacing the lamp, disconnect the appliance from the power supply.
  • Page 8: Product Description

    www.aegaustralia.com.au | www.aegnewzealand.co.nz 4. PRODUCT DESCRIPTION 4.1 General overview Control panel Electronic programmer Socket for the food temperature sensor Heating element Lamp Fans and heating elements Shelf support, removable Shelf positions...
  • Page 9 English 4.2 Accessories Food Sensor Wire shelf To measure the temperature inside For cookware, cake tins, roasts. the food. Grill shelf Telescopic runners Grill- / Roasting pan 2 x Left 2 x Right For shelves and trays. Shelf support / Side racks To bake and roast or as a pan to collect fat.
  • Page 10: Control Panel

    www.aegaustralia.com.au | www.aegnewzealand.co.nz ENGLISH 5. CONTROL PANEL 5. CONTROL PANEL 5.1 Electronic programmer 5.1 Electronic programmer Use the sensor fields to operate the appliance. Sensor Function Comment Use the sensor fields to operate the appliance. field Sensor field Function Comment Display Shows the current settings of the appliance.
  • Page 11 English 5.2 Display 5.2 Display A. Heating funct B. Time of day C. Heat-up indic D. Temperature A. Heating function E. Duration time B. Time of day C. Heat-up indicator function D. Temperature E. Duration time or end time of a function Other indicators of the display: Other indicators of the display: Icon...
  • Page 12: Before First Use

    www.aegaustralia.com.au | www.aegnewzealand.co.nz 6. BEFORE FIRST USE 6.2 First Connection When you connect the appliance to the WARNING! Refer to Safety chapters. mains or after the power cut, the display contrast, the display brightness and the 6.1 Initial Cleaning time of the day need to be set. Remove all accessories and removable shelf supports from the appliance.
  • Page 13 English 7.2 The menus in overview Submenu for: Basic Settings Sensor field Submenu Description Set Time of Day Sets the current time on the clock. When ON, the display shows the current time when you Time Indication deactivate the appliance. Fast heat up When ON, the function decreases the heat-up time.
  • Page 14 www.aegaustralia.com.au | www.aegnewzealand.co.nz 7.3 Heating Functions Submenu for: Basic Settings Heating Function Application Conventional Cooking (Top / To bake and roast food on one shelf position. Bottom Heat) To bake on up to three shelf positions at the same time and to dry food. Set the True Fan Cooking temperature 10 - 20°C lower than for the function: Conventional Cooking.
  • Page 15: Clock Functions

    English 7.4 Specials Heating Function Application Keep Warm To keep food warm. Plate Warming To preheat plates for serving. Preserving To preserve fruits and vegetables in sterilized cans and jars To dry sliced fruit (e.g. apples, plums, peaches) and vegetables Drying (e.g.
  • Page 16: Roast Modes

    www.aegaustralia.com.au | www.aegnewzealand.co.nz If you set the time for a clock function, the 2. Select the heating function. time starts to count down after 5 seconds. 3. Set the temperature above 80 °C. If you use the clock functions: 4. Press again and again until the Duration, End Time, the appliance display shows: Heat + Hold.
  • Page 17: Using The Accessories

    English When you use ‘Manual’ mode, the remain in the dish and the plug in the appliance uses the recommended socket. settings. You can change them as • Use recommended food core with other functions when using temperature settings. Refer to “Hints Assisted cooking Food Sensor or and tips”...
  • Page 18 www.aegaustralia.com.au | www.aegnewzealand.co.nz 8. Remove the food sensor plug from the The display shows the food sensor socket and remove the dish from the symbol. appliance. 6. Press or in less than 5 seconds to set the food core temperature. WARNING! There is a risk of burns 7.
  • Page 19 English...
  • Page 20 English Installing the side racks Positioning the dishes on the grill dish carrier 1. Insert the twin pegged side into the Installing the side racks Positioning the dishes on the grill dish carrier rear access holes provided, ensuring Installing the side racks Positioning the dishes on the grill dish carrier Insert the twin pegged side into the rear access holes pegs are fully inserted.
  • Page 21: Additional Functions

    www.aegaustralia.com.au | www.aegnewzealand.co.nz 11. ADDITIONAL If the Pyrolysis function operates, the door locks automatically. FUNCTIONS A message comes on in the display 11.1 Favourites when you touch any symbol. You can save your favourite settings, 1. Touch to activate the display. such as duration, temperature or 2.
  • Page 22: Hints And Tips

    English function starts. When the heating function surfaces of the appliance cool. If you ends, an acoustic signal sounds. deactivate the appliance, the cooling fan can continue to operate until the • Function Lock is on when the appliance cools down. heating function operates.
  • Page 23 www.aegaustralia.com.au | www.aegnewzealand.co.nz to the appliance you had before. Adapt your usual settings such as temperature, cooking time and shelf position to the values in the tables. • Use the lower temperature the first time. • If you cannot find the settings for a special recipe, look for the similar one.
  • Page 24 English 12.3 Tips on baking Baking results Possible cause Remedy The bottom of the cake is The shelf position is incorrect. Put the cake on a lower shelf. not browned sufficiently. The cake sinks and becomes The next time you bake, set a slightly lower The oven temperature is too high.
  • Page 25 www.aegaustralia.com.au | www.aegnewzealand.co.nz 12.4 Baking on single level Baking in tins Food Function Temperature (°C) Time (min) Shelf position Ring cake / Brioche True Fan Cooking 150 - 160 50 - 70 Madeira cake / Fruit cakes True Fan Cooking 140 - 160 70 - 90 Fatless sponge cake...
  • Page 26 English Biscuits Food Function Temperature (°C) Time (min) Shelf position Short pastry biscuits True Fan Cooking 150 - 160 10 - 20 Short bread / Pastry stripes True Fan Cooking 20 - 35 Conventional Short bread / Pastry stripes 20 - 30 Cooking Biscuits made with sponge mixture True Fan Cooking...
  • Page 27 www.aegaustralia.com.au | www.aegnewzealand.co.nz 12.6 Moist Fan Baking Food Temperature (°C) Time (min) Shelf position Pasta gratin 200 - 220 45 - 55 Potato gratin 180 - 200 70 - 85 Moussaka 170 - 190 70 - 95 Lasagne 180 - 200 75 - 90 Cannelloni 180 - 200...
  • Page 28 English 12.8 Pizza Setting Food Temperature (°C) Time (min) Shelf position Pizza (thin crust) 15 - 20 200 - 230 1)2) Pizza (with a lot of topping) 180 - 200 20 - 30 Tarts 180 - 200 40 - 55 Spinach flan 160 - 180 45 - 60...
  • Page 29 www.aegaustralia.com.au | www.aegnewzealand.co.nz Pork Food Quantity Function Temperature (°C) Time (min) Shelf position Shoulder / Neck / Ham joint 1 - 1.5 kg Turbo Grilling 160 - 180 90 - 120 Chop / Spare rib 1 - 1.5 kg Turbo Grilling 170 - 180 60 - 90 Meatloaf...
  • Page 30 English 12.11 Grilling CAUTION! Always grill with the oven door closed. • Set the shelf into the shelf position as recommended in the grilling table. • Always set the pan to collect the fat. • Grill only flat pieces of meat or fish. •...
  • Page 31 www.aegaustralia.com.au | www.aegnewzealand.co.nz Food Temperature (°C) Time (min) Shelf position Wedges / Croquettes 220 - 230 20 - 35 Hash Browns 210 - 230 20 - 30 Lasagne / Cannelloni, fresh 170 - 190 35 - 45 Lasagne / Cannelloni, frozen 160 - 180 40 - 60 Oven baked cheese...
  • Page 32 English 12.14 Defrost • Do not cover the food with a bowl or a plate, as this can extend the defrost time. • Remove the food packaging and put the food on a plate. • Use the first shelf position from the bottom. Food Quantity Defrosting time (min) Further defrosting time (min) Comments Put the chicken on an upturned saucer...
  • Page 33 www.aegaustralia.com.au | www.aegnewzealand.co.nz 12.16 Drying • For a better result, stop the oven halfway through the drying time, open the door • Cover trays with grease proof paper or and letit cool down for one night to baking parchment. complete the drying. Vegetables Food Temperature (°C) Time (h)
  • Page 34 English Beef Food core temperature (°C) Less Medium More Chop (saddle), Smoked pork loin, Smoked loin poached Pork Food core temperature (°C) Less Medium More Ham, Roast Chop (saddle), Smoked pork loin, Smoked loin poached Veal Food core temperature (°C) Less Medium More...
  • Page 35: Care And Cleaning

    www.aegaustralia.com.au | www.aegnewzealand.co.nz Casseroles - Precooked Food core temperature (°C) vegetables Less Medium More Zucchini Casserole, Broccoli Casserole, Fennel Casserole Casseroles - Savoury Food core temperature (°C) Less Medium More Cannelloni, Lasagne, Pasta bake Casseroles - Savoury Food core temperature (°C) Less Medium More...
  • Page 36 English Removing the shelf supports Option Description • Grasp the shelf support at the front. • Pull it firmly inwards. Quick 1 h for a low degree of dirt Normal 1 h 30 min for a usual degree of dirt Intense 3 h for a high degree of dirt 4.
  • Page 37 www.aegaustralia.com.au | www.aegnewzealand.co.nz • Clean the glass using detergent and WARNING! Do not use harsh warm water. Wipe clean and dry abrasive cleaners or sharp metal thoroughly. scrapers to clean the oven door • The outside glass cannot be removed since they can scratch the surface, from the door and hence can be which may result in shattering of...
  • Page 38 English 13.5 Changing the light globes • Switch the appliance off at the isolation switch before attempting to change the light globe. • There are 2 light globes located in the top of the oven cavity towards the rear. • To get access to the globes, firstly drop the element down as explained under ‘Releasing the grill element’...
  • Page 39: Troubleshooting

    English 14. TROUBLESHOOTING WARNING! Refer to Safety chapters. 14.1 What to do if... Problem Possible cause Remedy You cannot activate or The oven is not connected Check if the oven is correctly connected to operate the oven. to an electrical supply or it is the electrical supply (refer to the connection connected incorrectly.
  • Page 40: Installation

    English 15. INSTALLATION WARNING! Refer to Safety chapters. Underbench installation Your underbench oven looks best when the control panel is directly under the benchtop. An upper infill panel may be added if the cooktop placed above the benchtop is too deep.
  • Page 41 www.aegaustralia.com.au | www.aegnewzealand.co.nz Cabinet construction for built in oven NOTE: Your appliance must be mounted on a horizontal surface for the full width and depth of the product. For the best integration within a kitchen, install this appliance in a cupboard that gives NOTE: A ventilation slot 20mm wide is required a flush fit with the surrounding cupboard at the rear of the base of the cabinet floor.
  • Page 42 www.aegaustralia.com.au | www.aegnewzealand.co.nz To prevent tipping, use the screws supplied to secure your oven into the cupboard. Use just 2 screws for underbench oven installation. Mounting holes Use long black installation screws...
  • Page 43 (to allow smoke to escape). • Run the grill on high for 30 minutes Supply cord size required without grill dish. BPK722910M - 4mm2 • Then run the oven on 220°C for 1 hour. Data plate gives information Connecting to services and...
  • Page 44 www.aegaustralia.com.au | www.aegnewzealand.co.nz Plastic clips Plastic clips Plastic clip Plastic clip Securing points Securing points Electrical connection location - Model EVEP916SB Electrical connection location - Model EVEP916SB Entry point of electrical cable Entry point of electrical cable...
  • Page 45: Energy Savings

    English 16. ENERGY SAVING Moist Fan Baking Function designed to save energy during cooking. It operates in such a way that The oven contains features the temperature in the oven cavity may which help you save energy differ from the temperature indicated on during everyday cooking.
  • Page 46: Warranty

    (c) cosmetic damage which does not affect the operation of the Appliance; This document sets out the terms and conditions of the product warranties for AEG Appliances. It is an important document. Please keep it with your proof (d) damage to the Appliance caused by: of purchase documents in a safe place for future reference should there be a (i) negligence or accident;...
  • Page 47 Australia PLEASE CALL 13 13 50 OR EMAIL customercare@aegaustralia.com.au For the cost of a local call (Australia only) AEG SERVICE NEW ZEALAND www.aegnewzealand.co.nz FOR SERVICE or to find the address of your nearest state service centre in New Zealand FREE CALL 0800 10 66 10 OR EMAIL customercare@electrolux.co.nz...
  • Page 48 © 2017 Electrolux Home Products Pty Ltd ABN 51 004 762 341 P/No: A12345101 Rev 001 ECN 086520 AMAN_90cmPyro_Nov17...
