Room On/Off
Press and release
to turn on the UNO
System Keypad. This also turns on the corre-
sponding CAM6.6's room, and any presets previ-
ously assigned will be activated, including set-
tings for bass, volume, last source selected,
etc. Press and release
System Keypad. This will also put the corresponding
CAM6.6's room into a standby state.
System All On/Off
An "All On" command is issued by pressing
and holding for 3 seconds, after an initial room
has been turned on. An "All Off" command can
be issued to all rooms by pressing and holding
after the room has been turned off.
System On Indicator
When the room is off, but the system is on in
another room,
is illuminated by a green
backlight and the "SYS ON" icon remains visible.
Source Select Button
scrolls through the six audio source inputs.
To change sources, press and release
the sources are sequentially selected, each
source's name appears on the keypad LCD
panel. When a source is selected in more than
one room, the "SHARED" icon will appear on all
UNO Keypads using that source.
to turn off the UNO
. As
is also

UNO-S2 Keypad Button Function

used to enter the User Menu with a press and
hold action. (See next page for User Menu)
Volume Up/Down Buttons
The room's audio output is adjusted using
F1 and F2 Buttons
buttons are user favorite pre-
sets. These presets can be selected at any time
to recall source selection, volume, and favorite
channel, disk, etc. To store a favorite preset: first,
adjust the room settings and select a source to be
stored. Next, press and hold the desired
button until SAVED is displayed on the LCD
panel. Now a press and release of the button will
recall the favorite preset. To set a favorite num-
bered disk or channel, use
disk or channel (e.g., channel 45). Wait for the
keypad to show the source name, then press
and hold the F1 or F2 within 15 seconds of set-
ting the numeric selection to save the setting.
Command Keys
The command keys allow control of the selected
source at the UNO Keypad. The command keys are
activated with a press and release, or press and
hold to access secondary functions.
to select a
