The port-based LEDs can be cycled between three display modes: Status,
Duplex, and Speed. Pushing the mode button causes the display mode to be
cycled.
Mode
Status
Duplex
Speed
Table 4: Port Status behavior definition
®
RuggedCom
Color
Green (Solid)
Green (Blinking)
Off
Green (Solid)
Orange (Solid)
Off
Green (Blinking)
Green (Solid)
Orange (Solid)
Off
16
®
RuggedSwitch
RSG2288 Installation Guide rev106
Description
Link detected
Activity
No link
Full-Duplex operation
Half-Duplex operation
No link
1000Mb/s
100Mb/s
10Mb/s
No link
