Important Notes

Restrictions in Use
IDT's ZSSC4151 SSC Evaluation Kit, consisting of the SSC Communication Board (SSC CB), ZSSC415x/6x/7x Evaluation Board (SSC
EB), Sensor Replacement Board (SSC RB), and Evaluation Software, is designed for sensor module evaluation, laboratory setup, and
module calibration development only. IDT's SSC Evaluation Kit hardware and software must not be used for module production or
production test setups.
The related product ZSSC4151 SSC Mass Calibration System is designed only for development, evaluation, and laboratory setup of
sensor modules with IDT Sensor Signal Conditioner ICs. The IDT Mass Calibration System hardware and software must not be used for
module production and production test setups.
Disclaimer
IDT shall not be liable for any damages arising out of defects resulting from
(i)
delivered hardware or software
(ii) non-observance of instructions contained in this manual and in any other documentation provided to user, or
(iii) misuse, abuse, use under abnormal conditions, or alteration by anyone other than IDT.
To the extent permitted by law, IDT hereby expressly disclaims and user expressly waives any and all warranties, whether express,
implied, or statutory, including, without limitation, implied warranties of merchantability and of fitness for a particular purpose, statutory
warranty of non-infringement, and any other warranty that may arise by reason of usage of trade, custom, or course of dealing.
Contents
1
Evaluation Kit Contents and Overview ............................................................................................................. 3
2
ZSSC415x/6x/7x Evaluation Board .................................................................................................................. 5
2.1.
Overview .................................................................................................................................................... 5
2.2.
ZSSC415x/6x/7x SSC Evaluation Board Schematic ................................................................................. 6
2.3.
2.4.
2.5.
Connections between the ZSSC4151 IC and the Evaluation Board ......................................................... 8
3
Ordering Information ........................................................................................................................................ 9
4
Related Documents .......................................................................................................................................... 9
5
Glossary ........................................................................................................................................................... 9
6
Document Revision History ............................................................................................................................ 10
© 2016 Integrated Device Technology, Inc.
ZSSC4151 Evaluation Kit Hardware Manual
1
March 11, 2016

Advertisement

Table of Contents
loading

Related Manuals for IDT ZSSC4151

Summary of Contents for IDT ZSSC4151

  • Page 1: Table Of Contents

    The related product ZSSC4151 SSC Mass Calibration System is designed only for development, evaluation, and laboratory setup of sensor modules with IDT Sensor Signal Conditioner ICs. The IDT Mass Calibration System hardware and software must not be used for module production and production test setups.
  • Page 2 Bu1 Signal Connections: ZSSC415x/6x/7x Evaluation Board and SSC Communication Board ..7 Table 2.3 K10 Signal Connections: ZSSC415x/6x/7x Evaluation Board and Sensor Replacement Board ..7 Table 2.4 Signal Connections: ZSSC415x/6x/7x Evaluation Board and the ZSSC4151 QFN24....... 8 © 2016 Integrated Device Technology, Inc. March 11, 2016...

  • Page 3: Evaluation Kit Contents And Overview

    Note: There is a “dummy” IC in the socket on the ZSSC415x/6x/7x SSC Evaluation Board that should be replaced with an actual ZSSC4151 device under test (DUT). Refer to Figure 1.1 for the location of pin 1 for proper IC orientation.
  • Page 4 On the SRB, the sensor replacement signal is controlled by a potentiometer and provides a signal ranging from 2mV to 110mV to the analog front-end of the ZSSC4151 (BRN and BRP pins via the BR1N and BR1P pins respectively on the K10 connector; see Figure 2.2) and a temperature sensor signal from a 1N4148 diode to the ZSSC4151 temperature input (TS1 or TS2 pin, selectable by jumper K8, see Figure 2.1).

  • Page 5: Zssc415X/6X/7X Evaluation Board

    Headers for connections for external Sensor 1 or Sensor 2 modules. K4, K6 Strips for access to all ZSSC4151 signals; can be used to connect directly to the ZSSC4151 for in-circuit programming. Connects KS5V supply to VDDE pin (leave open when external power supply VDDE2 is connected); provides test points for simple supply current measurements.

  • Page 6: Zssc415X/6X/7X Ssc Evaluation Board Schematic

    ZSSC4151 Evaluation Kit Hardware Manual 2.2. ZSSC415x/6x/7x SSC Evaluation Board Schematic Figure 2.2 ZSSC415x/6x/7x SSC Evaluation Board Schematic © 2016 Integrated Device Technology, Inc. March 11, 2016...

  • Page 7: Connections Between The Communication Board And Zssc415X/6X/7X Evaluation Board

    C™; not applicable to ZSSC4151). MISO, SCK Bi-directional I/O port with ZSSC4151-internal pull-up resistors; a pull-up resistor from KS5V with a resistance of 4.7kΩ (on the CB) can be enabled by setting the SSC CB microcontroller port pin G3 low via the PS_G30 terminal command.

  • Page 8: Connections Between The Zssc4151 Ic And The Evaluation Board

    Connections between the ZSSC4151 IC and the Evaluation Board Table 2.4 gives the descriptions for the signals on the K6 and K4 connectors (see Figure 2.1) and the relevant ZSSC4151 IC pins. Table 2.4 Signal Connections: ZSSC415x/6x/7x Evaluation Board and the ZSSC4151 QFN24 Evaluation Evaluation Board...

  • Page 9: Ordering Information

    ZSSC4151 Evaluation Kit Hardware Manual Ordering Information Visit www.IDT.com/ZSSC415xKIT for current product ordering codes and descriptions. After a ZSSC4151 Evaluation Kit has been ordered, individual parts can be ordered separately. Sales contact information is provided on page 10. Related Documents...

  • Page 10: Document Revision History

    IDT's products are not intended for use in applications involving extreme environmental conditions or in life support systems or similar devices where the failure or malfunction of an IDT product can be reasonably expected to significantly affect the health or safety of users. Anyone using an IDT product in such a manner does so at their own risk, absent an express, written agreement by IDT.
