Pro-Form 595 HR User Manual page 12

To reset the displays, press the On/Reset button.
Note: The con-
sole can show
speed and dis-
tance in either
miles or kilome-
ters. The letters
MPH or KM/H will appear in the lower section of
the large display to show which system of mea-
surement is selected. To change the system of
measurement, hold down the On/Reset button for
about six seconds. Note: When the button is held
down, the fan will turn on for a moment. When
the batteries are replaced, it may be necessary to
reselect the desired system of measurement.
Measure your heart rate if desired.
5
If there are thin
sheets of plas-
tic on the
metal contacts
on the hand-
Metal
grips, peel off
Contacts
the plastic. To
use the hand-
grip pulse sen-
sor, hold the handgrips with your palms resting
against the metal contacts. Avoid moving your
hands. When your pulse is detected, the heart-
shaped indicator in the large display will flash
each time your heart beats. After a moment, two
dashes (– –) will appear and then your heart rate
will be shown.
For the most accurate heart rate reading, contin-
ue to hold the handgrips for about 30 seconds.
Note: When you first hold the handgrips, the
large display will show your heart rate continu-
ously for 30 seconds. The display will then show
your heart rate along with other feedback modes.
Turn on the fan if desired.
6
To turn on the
fan at low speed,
press the fan
button. To turn
Thumb
on the fan at
Wheel
high speed,
Fan
press the fan
Button
button a second
time. To turn off
the fan, press the fan button a third time. Note: If
the fan is turned on but the pedals are not moved
for thirty seconds, the fan will automatically turn
off to conserve the batteries.
Rotate the thumb wheel on the right side of the
console to pivot the fan to the desired angle.
When you are finished exercising, the console
7
will automatically turn off.
If the pedals are not moved for a few seconds,
the displays will pause and the time will flash in
the large display.
If the pedals are not moved and the console but-
tons are not pressed for a few minutes, the con-
sole will turn off to conserve the batteries.
12
HOW TO USE A SMART PROGRAM
Each Smart program will automatically change the
resistance of the pedals and prompt you to increase or
decrease your pace as it guides you through an effec-
tive workout. Programs 3 and 4 are weight loss pro-
grams, programs 5 and 6 are aerobic programs, and
programs 7 and 8 are high-performance programs.
Follow the steps below to use a Smart program.
Turn on the console.
1
See step 1 on page 11.
Select one of the Smart programs.
2
Each time the console is
turned on, the manual
mode will be selected. To
select a Smart program,
press the Program button
repeatedly until the number
3, 4, 5, 6, 7, or 8 appears
in the small display.
Begin pedaling to start the program.
3
To start the program, simply begin pedaling. Each
Smart program consists of 20 or 30 one-minute
periods. One resistance level and one target pace
are programmed for each period. (The same
resistance level and/or target pace may be pro-
grammed for two or more consecutive periods.)
At the end of each period of the program, the
resistance of the pedals will automatically change
if a different resistance level is programmed for
the next period. Note: If the resistance level is too
high or too low, you can change it by pressing the
+ and – buttons below the large display. However,
when the current period is completed, the resis-
tance of the pedals will automatically change if a
different resistance level is programmed for the
next period.
The target pace
for the current
Indicator
period will be
Bar
shown by the
arrows in the
Arrows
small display. To
pedal at the target
pace, simply
increase or decrease your pace until there is one
arrow pointing to each segment of the indicator
bar (see the drawing above). At the end of each
period, the number of arrows will change if a dif-
ferent target pace is programmed for the next
period. When the number of arrows changes,
change your pace until there is one arrow pointing
to each segment of the indicator bar. Important:
The target pace is intended only to provide a
goal. Your actual pace may be slower than the
target pace, especially during the first few
months of your exercise program. Make sure
to pedal at a pace that is comfortable for you.
During the program, the center of the large dis-
play will show the time remaining in the program.
If you stop pedaling for a few seconds, the dis-
plays will pause and the time will flash. If you con-
tinue pedaling after the program is completed, the
displays will continue to show exercise feedback.
Follow your progress with the large display.
4
See step 4 on page 11.
Measure your heart rate if desired.
5
See step 5 on page 12.
Turn on the fan if desired.
6
See step 6 on page 12.
When you are finished exercising, the console
7
will automatically turn off.
See step 7 on page 12.
13
