PART LIST—Model No. PFEVEL48940
Key No. Qty. Description
1 1 Frame
2 1 Upright
3 1 Left Side Shield
4 1 Right Side Shield
5 2 Handlebar Leg
6 1 Left Handlebar
7 1 Pivot Axle
8 1 Right Handlebar
9 1 Rear Stabiliser
10 1 Front Stabiliser
11 2 Pedal Spring
12 1 Left Rear Spring Bracket
13 1 Left Pedal
14 1 Right Pedal
15 2 Pedal Disc
16 2 Disc Crossbar
17 1 Flywheel
18 1 Side Shield Bracket
19 1 Drive Belt
20 2 Rear Endcap
21 2 Front Endcap
22 2 Wheel
23 1 Console
24 2 Handgrip
25 1 Idler Bracket
26 2 Idler Washer
27 2 Idler Bearing
28 1 Idler Axle
29 2 M3 x 12mm Screw
30 2 Large Snap Ring
31 2 Large Bearing
32 1 Pedal Axle
33 9 M10 Nylon Locknut
34 4 M10 x 75mm Carriage Bolt
35 2 Spring Bracket Washer
36 12 M6 x 33.5mm Flat Head Bolt
37 4 Pedal Arm Bushing
38 5 M8 Nylon Locknut
39 1 Flywheel Washer
40 2 M10 x 27mm Patch Screw
41 2 M10 x 45mm Bolt
42 4 M5 Washer
43 2 Wave Washer
44 1 Extension Wire Harness
45 1 Resistance Control Motor
Note: # indicates a non-illustrated part. Specifications are subject to change without notice.
R0704A
Key No. Qty. Description
46 2 Handlebar Cap
47 2 Handlebar Spacer
48 2 Upright Spacer
49 6 Small Handlebar Bushing
50 4 M8 x 45mm Button Bolt
51 8 M6 x 28mm Screw
52 13 M4 x 16mm Screw
53 1 Reed Switch/Wire
54 1 Wire Clamp
55 2 Handlebar Washer
56 2 M8 x 25mm Patch Screw
57 1 M10 Flat Head Bolt
58 1 Magnet
59 7 M10 Split Washer
60 4 Large Handlebar Arm Bushing
61 2 5/16" x 25.4mm Hex Bolt
62 1 M10 x 60mm Screw
63 2 Spring Spacer
64 4 M4 x 25mm Screw
65 1 Water Bottle Holder
66 14 M6 Nylon Locknut
67 3 M10 x 25mm Button Screw
68 1 M8 x 22mm Flat Head Bolt
69 1 Push Nut
70 1 Right Rear Spring Bracket
71 2 M5 x 16mm Self-tapping Screw
72 2 M5 x 16mm Screw
73 1 Upright Extension
74 2 M10 Bolt Set
75 12 M6 Washer
76 2 Front Spring Bracket
77 2 M6 x 18mm Screw
78 5 M10 Washer
79 1 Wire Harness
80 2 M10 x 30mm Carriage Bolt
81 2 Pedal Knob
82 2 M5 x 14mm Self-tapping Screw
83 2 M5 Nylon Locknut
84 2 M10 x 72mm Button Bolt
85 2 Handlebar Endcap
86 2 M4 x 19mm Screw
# 2 Hex Key
# 1 Grease
# 1 User's Manual
22
IMPORTANT PRECAUTIONS
WARNING:
To reduce the risk of serious injury, read the following important precau-
tions before using the elliptical exerciser.
1. Read all instructions in this manual before
using the elliptical exerciser.
2. It is the responsibility of the owner to ensure
that all users of the elliptical exerciser are
adequately informed of all precautions.
3. Place the elliptical exerciser on a level sur-
face, with a mat beneath it to protect the
floor or carpet. Keep the elliptical exerciser
indoors, away from moisture and dust.
4. Inspect and properly tighten all parts regu-
larly. Replace any worn parts immediately.
5. Keep children under 12 and pets away from
the elliptical exerciser at all times.
6. The elliptical exerciser should not be used
by persons weighing more than 115 kg (250
lbs).
7. Wear appropriate exercise clothes when
using the elliptical exerciser. Always wear
athletic shoes for foot protection.
WARNING:
Before beginning this or any exercise program, consult your physician.
This is especially important for persons over the age of 35 or persons with pre-existing health prob-
lems. Read all instructions before using. ICON assumes no responsibility for personal injury or
property damage sustained by or through the use of this product.
8. Always hold the handgrip pulse sensor or the
handlebars when mounting, dismounting, or
using the elliptical exerciser.
9. The pulse sensor is not a medical device.
Various factors may affect the accuracy of
heart rate readings. The pulse sensor is
intended only as an exercise aid in determin-
ing heart rate trends in general.
10. Keep your back straight when using the ellip-
tical exerciser; do not arch your back.
11. If you feel pain or dizziness at any time
whilst exercising, stop immediately and
begin cooling down.
12. When you stop exercising, allow the pedals
to slowly come to a stop.
13. The elliptical exerciser is intended for
home use only. Do not use the elliptical
exerciser in a commercial, rental, or institu-
tional setting.
