Converting latitude and longitude coordinates to decimal degrees:
The latitude and longitude values are both displayed in the following format:
dddmm.mmmm where d = degrees and m = minutes
To convert the number of minutes to a decimal value, use the following formula:
Decimal value = Minutes / 60
Example:
ProSoft Technology Headquarters: Bakersfield, California, USA
Latitude: 3522.086288,N
Longitude: 11903.627399,W
Latitude decimal degrees: 35 + (22.086288 / 60) = 35.36810
Longitude decimal degrees: 119 + (3.627399 / 60) = -119.06046

6.3.6 ICX30.UTIL

The ICX30.UTIL tag array does not need to be edited.
