ProSoft Technology ICX30-HWC User Manual page 33

ICX30-HWC ♦ Industrial Cellular Gateway
3G Cellular (M2M)
New configurations are saved on a micro SD card if inserted allowing modem
reboot or configuration transfer via micro SD to another radio without loss of
configuration data/fields.
GRE Tunnel
Runt
Tunnel Destination Address
Tunnel TTL
Routing
IP Group
Netmask
Add Entry button
Delete Entry button
Apply Changes button
Reset button
ProSoft Technology, Inc.
June 22, 2015
Description
Enable or Disable GRE Tunnel
Enter the Tunnel Destination Address.
TIme a packet can remain on the network before being discarded.
Alows the configuration of multiple routes (optional).
Enter a specific IP Group
Enter a Netmask for the IP group.
Adds the IP Group and Netmask to the Routing table
Deletes selected entries from the Routing table
Click when you are satisfied with your GRE Tunnel settings
Resets all fields back to empty values.
Configuration Webpage
User Manual
Page 33 of 64
