MT600 Plus User Manual V1.0
MT600 Plus 4G GPS Tracker
User Manual V1.0
Preface
Congratulations on choosing the Mictrack MT600 Plus 4G Vehicle GPS tracker. This
manual shows how to easily program and setup the tracker for best results. Make sure to
read this manual carefully before using this product, so as to avoid delays or confusion
with it's operation. Please note that specifications and instructions are subject to change
without notice to facilitate product improvement. Updates and changes will be integrated
into the latest release. The manufacturer assumes no responsibility for any errors or
omissions in outdated documents.
http://www.mictrack.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Mictrack MT600 Plus
Summary of Contents for Mictrack MT600 Plus
- Page 1 User Manual V1.0 Preface Congratulations on choosing the Mictrack MT600 Plus 4G Vehicle GPS tracker. This manual shows how to easily program and setup the tracker for best results. Make sure to read this manual carefully before using this product, so as to avoid delays or confusion with it’s operation.
-
Page 2: Table Of Contents
MT600 Plus User Manual V1.0 Contents 1. Overview............................. 1 2. Application............................1 3. Specifications............................. 1 4. MT600 Plus and Accessories......................3 5. Unit Diagram............................3 6. Installation............................3 6.1 SIM Card installation......................3 6.2 LED Indications........................4 6.2.1 CHG-Charge indicator (RED).................. 4 6.2.2 SYS-System indicator (BLUE).................4 6.2.3 GPS-GPS indicator (GREEN)................. - Page 3 MT600 Plus User Manual V1.0 7.18 Unit Phone Calling Control (useful for SIM Card data cost saving)....11 8. App & PC Tracking platform....................... 11 8.1 Subscribe the server plan with your sales..............11 8.2 App install & Login......................11 8.3 PC login..........................
-
Page 4: Overview
MT600 Plus User Manual V1.0 1. Overview MT600 Plus is a multifunctional 4G GPS tracker, fully supporting 4G LTE mobile networks, and also can extend to support Fuel sensor, temperature sensor, door sensor and siren etc. It is commonly used to track and locate individual vehicles, motorbikes or boats, and is a valuable tool for enhanced fleet management. - Page 5 MT600 Plus User Manual V1.0 Item Specifications Working temperature -20°C to 60°C Humidity 5%~95% non-concretion 10 hours in power-saving mode, 4 hours in normal mode Working Hours 4G(blue), GPS(green), Power(red) LED Indicator Microphone & Speaker External (optional) Sensor 3D acceleration/movement sensor/ temperature sensor Antennas External 4G &...
-
Page 6: Mt600 Plus And Accessories
MT600 Plus User Manual V1.0 4. MT600 Plus and Accessories Optional accessories: Siren/Speaker/Microphone/Temperature sensor/door sensor/SOS/Relay 5. Unit Diagram 6. Installation 6.1 SIM Card installation Pay attention to the following items before installing the SIM card: Ensure the SIM card have enough balance ... -
Page 7: Led Indications
MT600 Plus User Manual V1.0 Ensure the SIM card disable PIN password and call forwarding function. Power off the device before installing the SIM card To install the SIM card, perform the following operations: Insert the SIM card into the SIM card plastic tray. -
Page 8: Gps-Gps Indicator (Green)
MT600 Plus User Manual V1.0 6.2.3 GPS-GPS indicator (GREEN) Status Description GPS Unavailable Quick flash GPS available 6.3 Device Button Instruction Button Description Insert the SIM tray to POWER ON the unit; Take out SIM tray to POWER OFF the unit... -
Page 9: J1 Connection (6Pin Wired)
MT600 Plus User Manual V1.0 6.5 J1 Connection (6PIN wired) When installing the device, please connect supplied wiring loom as follows: (or contact our sales team for help) Red: Connect to constant 12V Car Battery(+) Black: Connect to Earth (Chassis) Car battery(-) ... -
Page 10: Setup And Configuration
MT600 Plus User Manual V1.0 7. Setup and Configuration Note: When sending SMS command to the unit, do NOT use spaces or symbols not listed below. * and # are valid command parameters. 7.1 Setting Authorized Phone Numbers SMS Command format: mobile number+password+[command parameter] Note: Command Parameter here is the sequence of the mobile number i.e. -
Page 11: Sos Alarm (Optional)
MT600 Plus User Manual V1.0 Note: This link can to be opened on any Smart Phone to reveal the Google Maps Location of the unit at the time of request 7.3 SOS Alarm (optional) When the SOS button is pressed for 3 seconds, the unit will automatically send it’s location to authorized phone number via SMS, and also upload location data to the Web Tracking Platform server along with the status description “SOS”... -
Page 12: Door Siren Alarm (Optional)
MT600 Plus User Manual V1.0 7.10 Door Siren Alarm (optional) 7.10.1 Enable Door Siren Alarm SMS Command format : 130+password For example: 1300000 Unit Reply: SET DOOR SIREN ON 7.10.2 Disable Door Siren Alarm SMS Command format : 130+password For example: 1310000 Unit Reply: SET DOOR SIREN OFF 7.11 Over-Speed Alarm... -
Page 13: Set Apn (Access Point Name)
MT600 Plus User Manual V1.0 Note : The default is Greenwich Time (UTC). [i.e. Melbourne Australia = +10:00] 7.14 Set APN (Access Point Name) SMS Command format 1: #803# password#APN## For example : #803#0000#telstra.internet## SMS Command format 2: #803#password#APN#APN user name# APN password## For example: #803#0000#CMNET#INTERNET#INTERNET## Reply: SET GPRS APN OK. -
Page 14: Unit Phone Calling Control (Useful For Sim Card Data Cost Saving)
MT600 Plus User Manual V1.0 Unit Reply: SET SEND SMS:OFF. To turn SMS messages back ON SMS Command format: 161+password For example: 1610000 Unit Reply: SET SEND SMS:ON. Note : if you want to disable the SMS alerts, send 1600000 7.18 Unit Phone Calling Control (useful for SIM Card data cost saving) -
Page 15: Troubleshooting
MT600 Plus User Manual V1.0 8.3 PC login Web: www.trackits.com Choose “ID No.” Input your device’s ID number and password(default is 123456) 9. Troubleshooting Issues Caused Solutions 1>Data only SIM card and don't Please check the SIM card... - Page 16 This can be a common issue, especially when initially setting up a new unit, and the unit fails to reply to a correct SMS command sequence. If you have any questions please do not hesitate to contact us info@mictrack.com. http://www.mictrack.com...
