MP90-NB User Manual V1.0
NB-IoT OBD Tracker
User Manual V1.0
Preface
Congratulations on choosing Mictrack MP90-NB NB-IoT OBD GPS tracker. This
manual shows how to easily program and setup the tracker for best results. Make
sure to read this manual carefully before using this product, so as to avoid delays or
confusion with it's operation. Please note that specifications and instructions are
subject to change without notice to facilitate product improvement. Updates and
changes will be integrated into the latest release. The manufacturer assumes no
responsibility for any errors or omissions in outdated documents.
http://www.mictrack.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MP90-NB and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Mictrack MP90-NB

  • Page 1 User Manual V1.0 Preface Congratulations on choosing Mictrack MP90-NB NB-IoT OBD GPS tracker. This manual shows how to easily program and setup the tracker for best results. Make sure to read this manual carefully before using this product, so as to avoid delays or confusion with it’s operation.
  • Page 2: Table Of Contents

    MP90-NB User Manual V1.0 Contents 1. Overview............................. 1 2. Application...........................1 3. Specifications..........................1 4. MP90-NB and Accessories.....................2 5. Installation........................... 3 5.1 SIM Card installation......................3 5.2 Install the Device........................4 5.3 LED Indications........................4 5.3.1 SYS-System indicator (RED)....................4 5.3.2 GPS-GPS indicator (BLUE)....................4 6.
  • Page 3: Overview

    MP90-NB User Manual V1.0 1. Overview The MP90-NB is a plug-and-play NB-IoT OBD tracker without wiring. Easy install to any vehicle with a standard OBD II connector. It can be used locate, track and monitor the vehicle via SMS, PC Computer or Mobile APP. It is commonly used to track and locate individual vehicles, the user also can real time tracking and check the historical route travelled.
  • Page 4: Mp90-Nb And Accessories

    MP90-NB User Manual V1.0 Item Specifications Positioning Accuracy Hot start 1s on average Warm start 15s on average Cold start 30s on average Working temperature -20°C to 60°C Humidity 5%~95% non-concretion Internal LTE CAT M1/NB1 & GPS antennas Antenna Sensor...
  • Page 5: Installation

    MP90-NB User Manual V1.0 5. Installation 5.1 SIM Card installation Please read the following before installing the SIM card: Ensure the SIM card has minimum balance  Ensure the SIM card has caller ID and HSPA functions enabled  Ensure the SIM card PIN is disabled, and call forwarding not active ...
  • Page 6: Install The Device

    USB Cable. All the USB configuration instruction please refer to 6.1 Un-plug alarm If the MP90-NB was remove from the OBD connector, it will call the authorized phone numbers, and then send location data to the authorized phone number and upload location data to the Web Tracking Platform server along with the status description “DEF”...
  • Page 7: Low Battery Alarm (Internal Backup Battery)

    MP90-NB User Manual V1.0 6.2 Low battery Alarm (internal backup battery) When the unit’s internal backup battery is low, it will SMS the authorized phone number, and upload location data to the Web Tracking Platform server along with the status description “BLP”...
  • Page 8: Appendix

    7. Appendix Mictrack Config Tool User Guide V2.0 The guide is only show how to to Config the Mictrack devices with the tools, the process are: Download the Config Tools and USB Driver: https://drive.google.com/drive/folders/0B32J3VHnO7UOcHRHbm1LU3p2RlE Install the USB Driver ” PL-2303 Vista_Win7 Driver Installer”;...
  • Page 9 This can be a common issue, especially when initially setting up a new unit, and the unit fails to reply to a correct SMS command sequence. If you have any questions please do not hesitate to contact us info@mictrack.com. http://www.mictrack.com...
