INTEGRATED COLUMNS
RS1884FJ, RS2484FJ, RS3084FJ,
RS2484S & RS3084S models
INSTALLATION GUIDE
US CA
847985B
03.17

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RS1884FJ and is the answer not in the manual?

Questions and answers

Related Manuals for Fisher & Paykel RS1884FJ

Summary of Contents for Fisher & Paykel RS1884FJ

  • Page 1 INTEGRATED COLUMNS RS1884FJ, RS2484FJ, RS3084FJ, RS2484S & RS3084S models INSTALLATION GUIDE US CA 847985B 03.17...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS  SAFETY AND WARNINGS  INTEGRATED COLUMNS  COMPONENTS LIST  PRODUCT DIMENSIONS AND SPECIFICATIONS  CABINETRY OPTIONS  CAVITY DIMENSIONS  DOOR AND TOE KICK PANEL DIMENSIONS  CUSTOM DOOR PANEL DIMENSIONS  DOOR OPENING ROTATION  ELECTRICAL AND PLUMBING  BEFORE INSTALLATION  UNPACKING AND MOVING YOUR PRODUCT  ATTACH THE ANTI-TIP BRACKET  CONNECT TO WATER AND POWER SUPPLY  SINGLE INSTALLATION...

  • Page 4: Safety And Warnings

    WARNING! Cut Hazard Take care — panel edges are sharp. Failure to use caution could result in injury or cuts. WARNING! RS1884FJ RS2484FJ RS3084FJ This appliance is top-heavy and must be secured to prevent the possibility of tipping forward. To ensure that the appliance is stable under all loading conditions, the ...
  • Page 5  COMPONENTS LIST Installation kit (847677) — included with the appliance Door panel attachment kit (848191) For SS door panels: For Custom door panels: side bracket (6x) bracket slider (6x) side spacer bracket (6x) M4 hex key (1x) (838183) (838201) (846177) (844124) 8Gx16 mush washer screw M5x12 Phillips screw (30x) (30x) (840371) (845432)

  • Page 6: Components List

    RS1884FJ RS2484FJ, RS3084FJ, INTEGRATED COLUMNS RS2484S & RS3084S models COLONNES ENCASTRABLES RS1884FJ, RS2484FJ, RS3084FJ, RS2484S & RS3084S models Modèles RS1884FJ, RS2484FJ, RS3084FJ, SERVICE & WARRANTY RS2484S et RS3084S SERVICE ET GARANTIE ΣΈΡΒΙΣ ΚΑΙ ΕΓΓΎΗΣΗ Toe kick (1x) SERVIZIO E GARANZIA SERVICE &...
  • Page 7  COMPONENTS LIST Door panels Dual install joiner kit (CA: 24985) — included with the appliance (Freezer model only). Attached to back of appliance. Used for any of the dual install options shown below. Left/Right Left/Left Right/Right Fisher & Paykel (Stainless steel) Customers can supply their door panel is not included own Custom door panel to WALL...
  • Page 8  COMPONENTS LIST Hinge change kit — not included with the appliance and must be purchased separately. LEFT HINGE (LH) TO RIGHT HINGE (RH) RS18 (848186) RS24 (848188) RS30 (848190) Hinge change assembly (1x) 848184 848184 848184 Top (fixed) grille assembly (1x) 847375 847374 847372 RIGHT HINGE (RH) TO LEFT HINGE (LH)

  • Page 9: Product Dimensions And Specifications

     PRODUCT DIMENSIONS AND SPECIFICATIONS FRONT VIEW PROFILE VIEW RS18 RS24 RS30 PRODUCT DIMENSIONS inches (mm) inches (mm) inches (mm) Overall height of product 84” (2134) 84” (2134) 84” (2134) Overall width of product 17 3/4” (451) 23 3/4” (603) 29 3/4” (756) Overall depth of product 24”...

  • Page 10: Cabinetry Options

     CABINETRY OPTIONS FRAMELESS CABINETRY FRAMED CABINETRY (Frameless: Aligns the product/s with the cabinetry) (Framed: Aligns the product/s with the frame of the cabinetry) Frameless Framed Note: Images shown for single install. These options are also applicable for dual install.

  • Page 11: Cavity Dimensions

     CAVITY DIMENSIONS Note: These dimensions are intended for ‘Flush Installation’ only. Flush with front of cabinetry Frameless: finished return Framed: finished return cavity sides and top cavity sides and top PLAN VIEW SINGLE INSTALL DUAL INSTALL RS18 RS24 RS30 RS18 + RS24 RS18 + RS30 RS24 + RS24 RS24 + RS30...

  • Page 12: Door And Toe Kick Panel Dimensions

     DOOR AND TOE KICK PANEL DIMENSIONS RS18  RS24  RS30 DOOR PANEL DIMENSIONS (STAINLESS STEEL) inches (mm) inches (mm) inches (mm) Height of door panel 79 7/8" (2029) 79 7/8" (2029) 79 7/8" (2029) Width of door panel 17 3/4” (451) 23 3/4" (603) 29 3/4"...
  • Page 13  DOOR AND TOE KICK PANEL DIMENSIONS SINGLE INSTALL DUAL INSTALL 2” toe kick height 4” toe kick height 6” toe kick height 2 7/8” – 4” toe kick depth (with extra lower grille attached) measured from the front of the door...

  • Page 14: Custom Door Panel Dimensions

     CUSTOM DOOR PANEL DIMENSIONS Custom door panel dimensions 14 7/8” (378mm) 8” (203mm) Dimensions apply for the preparation and installation of Custom door panels. For Dwg and Dxf files of the below panel preparation download the 2” (51mm) folder on http://thekitchentools.fisherpaykel.com IMPORTANT! The thickness of the custom door panel can vary provided that the screws ●...
  • Page 15  CUSTOM DOOR PANEL DIMENSIONS 11 7/8” (302mm) 8” (203mm) 8 7/8” (225mm) 2” (51mm) 2” (51mm) 7/8” x Ø1/8” 3/4” x Ø1/8” (22mm x Ø2mm) 18mm x Ø2mm Do not place handle holes in marked areas to avoid clashing with panel attachment brackets 2 3/8”...

  • Page 16: Door Opening Rotation

     DOOR OPENING ROTATION For 90° door swing a hinge limiting bolt is supplied with your appliance. This pin fits in the boreholes of the top hinge (Z). WARNING! Before opening the doors, ensure that the appliance is stable. ● ● Follow these instructions to avoid risks that can cause serious ●...

  • Page 17: Electrical And Plumbing

     ELECTRICAL AND PLUMBING WARNING! Electric shock hazard! Assume all parts live. Disconnect supply before servicing ● ● Left side of cavity and installation. REAR OF CAVITY Floor Electrical and water connections must be within this space if located behind the appliance and must not protrude from the back wall. Note: We recommend to use an isolating switch that is easily accessible to the user after the appliance is installed.

  • Page 18: Before Installation

     BEFORE INSTALLATION IMPORTANT! Ensure your appliance is not exposed to any heat generating appliance eg cooktop, oven or dishwasher. ● ● The appliance has front and rear rollers for moving the appliance forward and backward. Do not move the appliance sideways to avoid damaging the rollers or the floor covering/surface. ●...

  • Page 19: Unpacking And Moving Your Product

     UNPACKING AND MOVING YOUR PRODUCT IMPORTANT! WARNING! Follow these instructions to avoid risks that can cause serious injury or death. Be careful when unpacking to prevent damage to the surface of your appliance. ● ● ● ● Ensure that the appliance is stable to prevent from tipping over when unpacking. Keep doors closed until the appliance has been moved to its installation location.

  • Page 20: Attach The Anti-Tip Bracket

     ATTACH THE ANTI-TIP BRACKET IMPORTANT! Required components/tools: anti-tip bracket assembly (843934) Ensure the appliance/s is stable when the door/s is open. The anti-tip bracket and fittings supplied must be fitted to the ● ● – 1x anti-tip bracket (843933) wall of the finished enclosure to withstand a 220lb (100kg) load. If installed correctly, this will prevent the possibility of –...

  • Page 21: Connect To Water And Power Supply

     CONNECT TO WATER AND POWER SUPPLY WARNING! IMPORTANT! Required components/tools: water filter installation kit (847678) The water connection instructions below are intended only for the professional Old water fittings (hose-sets) should not be reused. ● ● ● ● ● ● –...

  • Page 22: Single Installation

     SINGLE INSTALLATION Required components/tools: 4x cabinet depth alignment gauges (847760) ● ● Phillips screwdriver ● ● Installing depth alignment gauges Note: The alignment gauges are only temporary and removable after installation. Loosen the screws at the right Attach the alignment gauges and left, top and bottom corners so that the screw head passes of the door (A).
  • Page 23  SINGLE INSTALLATION IMPORTANT! Required components/tools: Phillips screwdriver or power driver (PH2 bit) at minimum torque setting Ensure that the hose is not run over when moving the appliance/s to prevent ● ● ● ● ruler damage and possible water leaks. ●...
  • Page 24  SINGLE INSTALLATION IMPORTANT! IMPORTANT! Ensure the doors are in line with the cabinetry front and the appliance is centered. Make sure to remove the depth alignment brackets before fixing the appliance inside ● ● ● ● All four corners of the appliance must be supported firmly onto the floor to the cabinetry.
  • Page 25  DUAL INSTALLATION IMPORTANT! Dual installation includes two appliances installed side by Required components/tools: side. Refer to ‘Cavity dimensions’ section for cabinetry 1x depth alignment gauge (847760) We recommend to place the appliance (Freezer) with water ● ● ● ● overall width for dual install. A joiner kit is required for Phillips screwdriver (powered drill) connection first into the cabinetry to allow you to check the ●...
  • Page 26  DUAL INSTALLATION Required components/tools: 4x depth alignment gauges (847760) ● ● Phillips screwdriver ● ● Installing depth alignment gauges Note: The alignment gauges are only temporary and removable after installation. Loosen the screws at the right Attach the alignment gauges and left, top and bottom corners so that the screw head passes of the door (A).
  • Page 27  DUAL INSTALLATION IMPORTANT! Required components/tools: ruler Make sure that all feet engage the floor and evenly support the product. Tighten the ● ● adjustment screw with screwdriver (do not use powered driver). Positioning and aligning the first appliance inside the cabinetry Align the top cap of the first appliance flush with the front of the spacer (B).
  • Page 28  DUAL INSTALLATION IMPORTANT! Required components/tools: Phillips screwdriver or power driver Ensure the doors are in line with the cabinetry front and the appliance is centered. ● ● ● ● 5x 8Gx16 countersunk screws (840597) All four corners of the appliance must be supported firmly onto the floor to eliminate any ●...

  • Page 29: Dual Installation

     DUAL INSTALLATION Required components/tools: ruler ● ● Positioning and aligning the second appliance inside the cabinetry Roll the second appliance into the cabinetry side by side with the first appliance. (A) Continue rolling the appliance into the cabinetry until the anti-tip bracket overlaps [minimum 7 1/8”...
  • Page 30  DUAL INSTALLATION IMPORTANT! Required components/tools: Phillips screwdriver or power driver (PH2 bit) at minimum torque setting Ensure the door is in line with the cabinetry front and the appliance is centered. ● ● ● ● All four corners of the appliance must be supported firmly onto the floor to eliminate any ●...
  • Page 31  DUAL INSTALLATION Required components/tools: Bottom joiner fastener kit (848312) 5x 8Gx16 countersunk screw (840597) ● ● ● ● top joiner fastener kit (848313) – 1x M6x16 washer screw (848869) M4 hex key (844124) ● ● ● ● – 1x M5x20 cap screw (847984) –...
  • Page 32  INSTALL WATER FILTER Required components/tools: 1x water filter (847200) ● ● 1x water filter removal tool (included with appliance) ● ● Flushing the water filter Remove the water filter packaging. Pull the filter tool gently to dislodge from the front of the appliance (A). Before turning on your automatic ice maker, the water Insert the water filter all the way into the filter casing and press firmly until the filter head is pushed further inside the casing (B).

  • Page 33: Install Brackets To Door Panel

     INSTALL BRACKETS TO DOOR PANEL (STAINLESS STEEL) IMPORTANT! Required components/tools: Door panel attachment kit (847678) drill with 3/32” (2.55mm) bit Ensure to protect the finish of the Fisher & Paykel Stainless Steel door panels. Leave ● ● ● ● ● ●...
  • Page 34  INSTALL BRACKETS TO DOOR PANEL (CUSTOM) IMPORTANT! Required components/tools: Door panel attachment kit (847678) drill with 3/32” (2.55mm) bit Ensure the screw pilot holes do not penetrate the full depth of the panel. ● ● ● ● ● ● – 6x side panel brackets (838183) powered driver (Phillips) Do not place the handle holes in marked areas to avoid clashing with panel ●...
  • Page 35  INSTALL DOOR PANELS IMPORTANT! IMPORTANT! Required components/tools: 4x M5x25 hex screws (842292) The assembly of Fisher & Paykel (Stainless steel) door We recommended to load the shelves in the ● ● ● ● 1x drill with 3/32” (2.55mm) bit panels and Custom door panels are outlined below. appliance door with weights to ensure an ●...
  • Page 36  INSTALL DOOR PANELS Required components/tools: 1x Phillips screwdriver ● ● M4 hex key ● ● 1/2” (13mm) spanner ● ● Adjust the door panel Fix the locking brackets Note: All door panels have full axis adjustment to ensure they are flush with adjacent walls. Loosen the screw at the bottom of the door, and slide the locking bracket out until it To adjust the height of the door panel relative to the door, use M4 hex key to turn the top touches the panel (D).
  • Page 37  INSTALL TOE KICK IMPORTANT! Required components/tools: Two magnets are pre-installed to the bottom corners of the toe kick mounting plate. Each 1x air kickstrip seal (846405) ● ● magnet has double-sided tape to be attached to the toe kick. This allows both Stainless 1x toe kick ●...

  • Page 38: Install Kickstrip Grille

     INSTALL KICKSTRIP GRILLE IMPORTANT! Required components/tools: hex key (supplied) For toe kick heights 4 1/2” – 5” (114 – 127mm), shorten the lower grille by cutting along the ● ● ● ● 1x fixed (top) grille vertical ribs. ● ● 1x bottom (movable) grille For 2” (51mm) toe kick height, an additional lower grille can be ordered. ●...
  • Page 39  INSTALL CABINET TRIMS Required components/tools: 1x alcove side trim assembly (848193) ● ● Install the side trims Note: Four (4) dual-lock strips are pre-installed along each side trim. Peel off the liners from the dual-lock strips. (A) Slide the trim behind the lower hinge (C), then the top Slot trim in behind top hinge pocket (E), then press (F) hinge (D).
  • Page 40  INSTALL CABINET TRIMS Required components/tools: Required components/tools: 1x center trim 1x top trim ● ● ● ● Install the center trims (for dual install only) Install the top trim Note: Four (4) dual-lock strips are pre-installed along the center trim. Slide the top trim into hinge pocket of the cabinet (A), and then engage the dual lock at the non-hinge side (B).

  • Page 41: Install Flow Divider And Door Trims

     INSTALL FLOW DIVIDER AND DOOR TRIMS IMPORTANT! Required components/tools: 1x door flow divider (843693) top door panel extrusion The door flow divider is pre-assembled to the door of the appliance. It blocks the air flow ● ● ● ● 1x flow divider cap (847957) 2x door panel side extrusion (843266) from bypassing in front of the bottom grille.

  • Page 42: Optional — Changing Over Door Hinges

     OPTIONAL — CHANGING OVER DOOR HINGES You have the option to change the door hinge side of your appliance from right hand Required components/tools: hinge to left hand hinge or vice versa. A hinge change kit is required for this installation. star T20 screwdriver ●...
  • Page 43  OPTIONAL — CHANGING OVER DOOR HINGES Required components/tools: star T20 screwdriver ● ● flat head screwdriver ● ● Removing the top door hinge Rotate the top hinge (A) outwards and remove the top hinge pocket cover (B) using the flat head screwdriver in the slot of the cover. Remove the hinge by unscrewing the M5x12 pan head screws (2x) (C), and set aside for later use.
  • Page 44  OPTIONAL — CHANGING OVER DOOR HINGES Required components/tools: star T20 screwdriver ● ● flat head screwdriver ● ● Moving the sensor housing (RS18 & RS24 only) Unclip the reed switch from the housing (A). Move the sensor housing so that the opposite reed switch Reinstall the sensor housing using #8x16 screws (2x) Unhook the interceptor board harness from sensor clip is aligned with the center of the cabinet (D).
  • Page 45  OPTIONAL — CHANGING OVER DOOR HINGES Required components/tools: left/right hinge change kit (refer to star T20 screwdriver ● ● ● ● ‘Components list’ for part numbers) flat head screwdriver ● ● – 1x top (fixed) grille assembly – hinge change assembly Top hinge installation Reinstall the hinge top bracket and bracket spacer with M5x12 countersunk screws (A) on the new hinge side at the other side of the...
  • Page 46  OPTIONAL — CHANGING OVER DOOR HINGES Required components/tools: 2x K05 top adapter bracket star T20 screwdriver ● ● ● ● RH (842935), LH (841982) Flat head screwdriver ● ● 2x K05 bottom adapter bracket ● ● RH (842890), LH (842889) Door brackets Remove the top adapter bracket from the top of the door by unscrewing M5x10 screws (4x) (A).
  • Page 47  OPTIONAL — CHANGING OVER DOOR HINGES Required components/tools: star T20 screwdriver ● ● flat head screwdriver ● ● hex driver ● ● Door installation Activate the hinge spring by turning the star T20 screws to the “I” position (B). Reinstall the door to the appliance by fixing M6x10 hex screws (4x) into the hinges (A). Top hinge Bottom hinge Return the appliance to the upright position.

  • Page 48: Final Checklist

     FINAL CHECKLIST TO BE COMPLETED BY THE INSTALLER All models Check all parts are installed. Ensure the appliance is level. Ensure the appliance is securely fastened to the cabinetry with the supplied anti-tip bracket and fittings. Ensure the door/drawer can open and close freely with no resistance from surrounding cabinetry.
