Fisher & Paykel 9 Series Installation Manual
Integrated columns
Hide thumbs
Also See for 9 Series:
- User manual (48 pages) ,
- Installation manual (20 pages) ,
- Quick reference manual (2 pages)
Related Manuals for Fisher & Paykel 9 Series
Summary of Contents for Fisher & Paykel 9 Series
- Page 1 INTEGRATED COLUMNS RS1884FJ, RS2484FJ, RS3084FJ, RS2484S & RS3084S models INSTALLATION GUIDE US CA 847985C 05.18...
- Page 3 TABLE OF CONTENTS SAFETY AND WARNINGS INTEGRATED COLUMNS COMPONENTS LIST PRODUCT DIMENSIONS AND SPECIFICATIONS CABINETRY OPTIONS CAVITY DIMENSIONS DOOR AND TOE KICK PANEL DIMENSIONS CUSTOM DOOR PANEL DIMENSIONS DOOR OPENING ROTATION ELECTRICAL AND PLUMBING BEFORE INSTALLATION UNPACKING AND MOVING YOUR PRODUCT ATTACH THE ANTI-TIP BRACKET CONNECT TO WATER AND POWER SUPPLY SINGLE INSTALLATION...
- Page 9 PRODUCT DIMENSIONS AND SPECIFICATIONS FRONT VIEW PROFILE VIEW RS18 RS24 RS30 PRODUCT DIMENSIONS inches (mm) inches (mm) inches (mm) Overall height of product 84” (2134) 84” (2134) 84” (2134) Overall width of product 17 3/4” (451) 23 3/4” (603) 29 3/4” (756) Overall depth of product 24”...
- Page 12 DOOR AND TOE KICK PANEL DIMENSIONS RS18 RS24 RS30 DOOR PANEL DIMENSIONS (STAINLESS STEEL) inches (mm) inches (mm) inches (mm) Height of door panel 79 7/8" (2029) 79 7/8" (2029) 79 7/8" (2029) Width of door panel 17 3/4” (451) 23 3/4" (603) 29 3/4"...
- Page 14 CUSTOM DOOR PANEL DIMENSIONS Custom door panel dimensions 14 7/8” (378mm) 8” (203mm) Dimensions apply for the preparation and installation of Custom door panels. For Dwg and Dxf files of the below panel preparation download the 2” (51mm) folder on http://thekitchentools.fisherpaykel.com IMPORTANT! The thickness of the custom door panel can vary provided that the screws ●...
- Page 15 CUSTOM DOOR PANEL DIMENSIONS 11 7/8” (302mm) 8” (203mm) 8 7/8” (225mm) 2” (51mm) 2” (51mm) 7/8” x Ø1/8” 3/4” x Ø1/8” (22mm x Ø2mm) 18mm x Ø2mm Do not place handle holes in marked areas to avoid clashing with panel attachment brackets 2 3/8”...
- Page 16 DOOR OPENING ROTATION For 90° door swing a hinge limiting bolt is supplied with your appliance. This pin fits in the boreholes of the top hinge (Z). WARNING! Before opening the doors, ensure that the appliance is stable. ● Follow these instructions to avoid risks that can cause serious ●...
- Page 18 BEFORE INSTALLATION IMPORTANT! Ensure your appliance is not exposed to any heat generating appliance eg cooktop, oven or dishwasher. ● The appliance has front and rear rollers for moving the appliance forward and backward. Do not move the appliance sideways to avoid damaging the rollers or the floor covering/surface. ●...
- Page 42 OPTIONAL — CHANGING OVER DOOR HINGES You have the option to change the door hinge side of your appliance from right hand Required components/tools: hinge to left hand hinge or vice versa. A hinge change kit is required for this installation. T20 star screwdriver ●...
- Page 48 FINAL CHECKLIST TO BE COMPLETED BY THE INSTALLER All models Check all parts are installed. Ensure the appliance is level. Ensure the appliance is securely fastened to the cabinetry with the supplied anti-tip bracket and fittings. Ensure the door/drawer can open and close freely with no resistance from surrounding cabinetry.
