Packet Structures
Byte Bit Function
0–4 Soft starter state
16
5 Warning
6 Initialized
7 Local control
0 Parameters
17
1 Phase sequence
2–7
4)
Trip code
0–13 Current
18–19
14–15 Reserved
0–13 Current (% motor FLC)
20–21
14–15 Reserved
22 0–7 Motor 1 thermal model (%)
23 0–7 Motor 2 thermal model (%)
0–11 Power
5) 12–13 Power scale
24–25
14–15 Reserved
26 0–7 % power factor
27 0–7 Reserved
28 0–7 Reserved
29 0–7 Reserved
0–13 Phase 1 current (rms)
30–31
14–15 Reserved
0–13 Phase 2 current (rms)
32–33
14–15 Reserved
0–13 Phase 3 current (rms)
34–35
14–15 Reserved
36 0–7 Reserved
37 0–7 Reserved
38 0–7 Reserved
39 0–7 Reserved
40 0–7 Reserved
41 0–7 Reserved
42 0–7 Parameter list minor revision
43 0–7 Parameter list major revision
0–3 Digital input state
44
4–7 Reserved
MG17M202
Installation Guide
Details
0 = Reserved.
1 = Ready.
2 = Starting.
3 = Running.
4 = Stopping.
5 = Not ready (restart delay, restart temperature check).
6 = Tripped.
7 = Programming mode.
8 = Jog forward.
9 = Jog reverse.
1 = Warning.
0 = Uninitialized.
1 = Initialized.
0 = Local control.
1 = Remote control.
0 = Parameters have changed since last parameter read.
1 = No parameters have changed.
0 = Negative phase sequence.
1 = Positive phase sequence.
See trip codes in Table 7.4.
Average rms current across all 3 phases.
–
–
–
–
–
–
–
–
100% = power factor of 1.
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
For all inputs, 0 = open, 1 = closed.
0 = Start.
1 = Stop.
2 = Reset.
3 = Input A
–
