4.3.

DESCRIPTION OF FUNCTION KEYS

4.3.1. ON/OFF key

Press the key to switch on or off the instrument. The LCD display shows all of its
segments for a moment. The key is also used to set the instrument s parameters (see §
'
5.1).

4.3.2. Arrow keys

The arrow keys , are used to set the instrument s parameters (see § 5.1) and to
'
select the cable pairs for measuring length (see § 5.5).

4.3.3. L/W key

Use the L/W key to:
 Go to the Mapping test screen (WIREMAP) and to the Length measuring screen
(LENGTH).
 Set the length measuring unit (see § 5.1.4).
 Define calibration operations of cable length (see § 5.5.1).

4.3.4. SET/UNIT key

Press the SET/UNIT key to select the current remote unit in case the test is performed with
more remote units present (see § 5.2.3). Press and hold the SET/UNIT key for 3s in order
to enter/exit the section for setting the internal parameters of the instrument and navigate
inside it (see § 5.1).

4.3.5. TEST/

Press the TEST/ key to activate a measuring test and to confirm the values of
parameters when programming the instrument (see § 5.1).
