Partner SP-2500 Quick Start Manual

SP-2500 Series Quick Start Guide
WARNING
The system uses a 3 V CR 2032 battery mounted on the mainboard to keep time. There
is a risk of explosion if the wrong battery type is used when replacing. Dispose of used
batteries according to local ordinance regulations.
WARNING
This is Class A Product. In domestic environment this product may cause radio interference
in which case the user may be required to take adequate measures.
警告使用者
這是甲類的資訊產品 ， 在居住的環境中使用時 ， 可能會造成射頻干擾 ， 在這種情況下 ， 使用者會被要求採
取某些適當的對策 。
Federal Communications Commission (FCC) Statement
This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications. Operation of this equipment in a residential
area is likely to cause harmful interference in which case users will be required to correct
the interference at their own expense

Safety information

• Before installing and using the machine, take note of the following precautions:
• Do not place the unit on an unstable surface, cart, or stand.
• Do not block the slots and opening on the unit, which are provided for ventilation.
• Only use the power source indicated on the marking label. If you are not sure,
contact your dealer or the Power Company.
• When replacing parts, ensure that your service technician uses parts specified by the
manufacturer.
• Do not place anything on the power cord. Place the power cord where it will not be in
the way of foot traffic.

Identifying components

Camera
MSR
IC Reader
2 D Scanner RFID
iButton/
Fingerprint
3 optional display sizes
RJ- 11 Cash drawer port
USB 24 V* USB 12 V*
DC 12 V-In
DC 12 V-Out USB 2 . 0
NOTE
Optional peripherals are sold
separately. (RFID and Camera
are factory options)
Power Button
Line-Out*
LAN COM 2 COM 4
USB 3 . 0 COM 1 COM 3
* optional connectors.
Audio jacks (Line-out & MIC) and LPT port, can only be chosen either one.
VGA 2 port is unavailable when main monitor is installed.
VGA 1 port is unavailable when secondary monitor is installed.
Secondary
Monitor
I/O Cover
I/O Panel
MIC* LPT*
VGA 2 * VGA 1 *
