1. FIRE IN CAVITY WALL. INSET FAN UNIT.
MINIMUM DIMENSION WILL
DEPEND UPON WALL THICKNESS
3. FIRE IN SPECIAL SURROUND OR FALSE
CHIMNEY BREAST. INSET FAN UNIT.
INSTRUCTIONS\ARTWORK\PARAGON 2000 TURBO\2000 TURBO SIDE VIEW
Ensure you have the power flue box that you require (Flush Mounted or Sunk in the Wall), and follow the
instructions for the appropriate power flue box.
www.charltonandjenrick.co.uk
IF THE APPLIANCE IS
TO BE SET BACK INTO THE
CAVITY , THE SPACE
BEHIND, TO THE SIDES
& ABOVE MUST BE INSULATED
IE: ROCKWOOL.
2. FIRE IN CAVITY WALL, FAN UNIT SURFACE MOUNTED
MINIMUM DIMENSION WILL
DEPEND UPON WALL THICKNESS
4. FIRE IN SPECIAL SURROUND OR FALSE CHIMNEY
BREAST. FAN UNIT SURFACE MOUNTED.
23
IF THE APPLIANCE IS
TO BE SET BACK INTO THE
CAVITY , THE SPACE
BEHIND, TO THE SIDES
& ABOVE MUST BE INSULATED
IE: ROCKWOOL.
LT5052 (ISS 5)
