- Page 1 UM1672 User manual SPC560B-DIS discovery board Introduction This document describes the hardware architecture of the board, how to configure the jumpers and to enable specific functions. November 2013 DocID025237 Rev 1 1/22 www.st.com...
-
Page 2: Table Of Contents
SPC560B-DIS discovery board with SPC560B54L5 ....5 SPC560B-DIS discovery board ....... . . 5 Debug interface . - Page 3 UM1672 List of tables List of tables Table 1. +12 V Supply configuration, S1 and S2 jumpers configuration..... . . 8 Table 2.
- Page 4 Figure 1. SPC560B-DIS discovery board with SPC560B54L5 ......5 Figure 2.
-
Page 5: Spc560B-Dis Discovery Board With Spc560B54L5
HVAC, Comfort Modules, Security Access and they are suitable for ASIL B/SIL requirements. SPC560B-DIS discovery board is supported by a specific application project inside SPC5Studio (a visual integrated software development environment to easily develop software for SPC56 MCU's), that embeds micro start-up routines, I/O mapping and a simple test codes SPC5Studio is available for download www.st.com/spc5studio. -
Page 6: Debug Interface
SPC560B-DIS discovery board with SPC560B54L5 UM1672 Debug interface The microcontroller can be debugged using both • JTAG standard 14 pins interface, for using external debugger tools • USB mini-B, through the PLS debugger integrated on board Microcontroller I/Os All microcontroller IOs are available on the two 2 x 36 headers with exception of JTAG, TCK, TMS, TDI, TDO, XTAL, EXTAL and VDD_LV pins. -
Page 7: Hardware Overview
UM1672 Hardware overview Hardware overview Figure 2. HW overview Power supply The discovery board allows wide supply configurations, such as: 12 V (external PSU) or 5 V (USB supply). 2.1.1 12 V DC power supply 12 V voltage can be used to supply the board using the PSU output barrel connector (+12 V) or directly from 2x36 headers. -
Page 8: Supply From Usb Port
Hardware overview UM1672 Table 1. +12 V Supply configuration, S1 and S2 jumpers configuration +12 V Supply configuration OPEN OPEN The board is not supplied with 12 V CLOSE OPEN The board is supplied by the external PSU The discovery board supplies the daughter board (+12 V connected to CLOSE CLOSE the discovery board) or the daughters supplies the discovery (+12 V... -
Page 9: Crystal Oscillator
UM1672 Hardware overview Crystal oscillator The SPC560B-DIS board could be populated either with 8 or 16 MHz crystal to clock the SPC560B54L5. Default configuration is with 16 MHz crystal. Figure 5. Crystal (PCB) Reset section In order to generate a clean reset signal for the microcontroller, STM6315RDW13F is used. -
Page 10: Programming And Debug
Hardware overview UM1672 Programming and debug The microcontroller in the discovery board can be programmed and debugged using two methods • Staport wndard JTAG connector (male 2x7 100mil - 90°) • USB with integrated debugger. A further configuration in addition to the previous configurations allows configuring the board as a standalone PLS adapter;... -
Page 11: Usb With Integrated Debugger From Pls (Default Configuration)
USB with integrated debugger from PLS (default configuration) The integrated debugger, based on the device FTDI2232H and UDE PLS software, allows the user to build, run and debug the software applications. The SPC560B-DIS discovery kit includes a full-featured, perpetual code-limited (128 Kbytes) PLS software license; the debugger serial number is reported on a label applied on the bottom side of the board. -
Page 12: Usb And Graphic User Interface (Gui)
Hardware overview UM1672 Table 3. Programming and debug - Jumper setting Jumper name JTAG PLS Adapter (Integrated debugger) J101 Open Close Close J102 Open Close Close J103 Open Close Close J105 Open Close Close J109 Open Close Close J110 Open Close Close J111... -
Page 13: User I/O Pins
UM1672 Hardware overview Figure 9. GUI: TX and RX signals with optocoupler User I/O pins Some microcontroller GPIOs are dedicated for user purpose. Here below details about to each group. 2.6.1 User LEDs The LEDs D7 and D8 are available for user purpose; the jumpers J9, J10 connect the 2 LEDs to the microcontroller I/O PC3 and PC2 respectively. -
Page 14: User I/O Pins
Hardware overview UM1672 Figure 11. User push button 2.6.3 User I/O pins Pin PC4 can be set to Low or High configuring J11. Figure 12. User I/O pins PC4, PA8 and PA9 2.6.4 Boot configuration It is possible to reprogram microcontroller internal flash programming using Boot Assist Mode (BAM) via SCI. -
Page 15: Daughter Board Connector And I/O Headers
UM1672 Hardware overview Figure 13. Potentiometers (Schematic & PCB) Daughter board connector and I/O headers The I/O microcontroller pins are connected to a double 2 x 36 pin array (connectors X1-X2 and X3-X4). Table 4. I/O headers Pin number VBAT VBAT PE[2] PE[3]... -
Page 16: Figure 14. I/O Headers (Schematic Diagram)
Hardware overview UM1672 Table 4. I/O headers (continued) Pin number PC[10] PG[7] PB[13] PD[13] PG[6] PC[9] PB[12] PD[12] PC[8] PF[9] PB[11] PD[11] PF[8] PF[12] PD[10] PD[9] PC[6] PC[7] PB[7] PB[6] PF[10] PF[11] PB[5] PB[4] PA[15] PF[13] PD[8] PD[7] PA[14] PA[4] PD[6] PD[5] PA[13]... -
Page 17: Pcb Layout
UM1672 Hardware overview PCB Layout Figure 15. PCB - Top Layer Figure 16. PCB – Inner Layer 2 DocID025237 Rev 1 17/22... -
Page 18: Figure 17. Pcb - Inner Layer 3
Hardware overview UM1672 Figure 17. PCB – Inner Layer 3 Figure 18. PCB – Bottom Layer 18/22 DocID025237 Rev 1... -
Page 19: Appendix A General Handling Precautions
UM1672 General handling precautions Appendix A General handling precautions The following precautions are recommended when using the SPC560B-DIS, discovery board: • Do not modify or manipulate the board when the external PSU supply is powered and connected to the board. -
Page 20: Appendix B Reference Documents
Reference documents UM1672 Appendix B Reference documents ® 32-bit MCU family built on the Power Architecture for automotive body electronics applications (Datasheet, Doc ID 15131). 20/22 DocID025237 Rev 1... -
Page 21: Revision History
UM1672 Revision history Revision history Table 5. Document revision history Date Revision Changes 04-Nov-2013 Initial release. DocID025237 Rev 1 21/22... - Page 22 No license, express or implied, by estoppel or otherwise, to any intellectual property rights is granted under this document. If any part of this document refers to any third party products or services it shall not be deemed a license grant by ST for the use of such third party products or services, or any intellectual property contained therein or considered as a warranty covering the use in any manner whatsoever of such third party products or services or any intellectual property contained therein.
