REPAIRS
AeroCell foam is easily reparable. Pliable glue such as canopy
glue is the very best, but requires tape to hold the parts together
while the glue dries overnight. CA is usually the go-to adhesive
for repairing AeroCell and with a little CA accelerator the repair
will be complete in minutes. For a seamless repair excess CA
may be removed from the surfaces with CA debonder (debonder
will affect the decals and paint).

MOTOR REMOVAL

If you ever have to remove the motor, the top and bottom
moveable motor mount halves must be separated. This is done
by taking out the top and bottom 4mm pivoting screws, the
four 3mm motor mount screws and fi nally the four self-tapping
screws holding the halves together.
Once the motor comes out with the top moveable mount,
disconnect the motor from the ESC and guide the wires out
through the molded-in retainer.
NOTE: If considering a different motor other than the 35-36-2200
(FLZA6522) included with this kit, make sure the orientation of the
mounting holes will allow the wires to align with the retainer in the
Motor wires
moveable mount. Otherwise, the motor will not fi t. 16mm
19mm
