Flyzone HADRON Manual page 11

SUPPLEMENTARY SETUP INSTRUCTIONS
Tactic TTX650 Programming
These instructions mix the vectoring and rudder servos and allow either to be turned off in-fl ight via switch E.
I. Servo Connections to Receiver
Ch. 1: Right Elevon Servo
Ch. 2: Left Elevon Servo
Ch. 3: Throttle
Ch. 4: Vacant-not used
Ch. 5: Vectoring Servo
Ch. 6: Rudder Servo
II. Radio Programming
A. MODEL SETUP (Press and hold "ENTER")
WING TYPE
FLAP: 2AI (2 Aileron)
TAIL: Delta
B. SETTINGS (Press "ENTER")
1. SERVO SET (Reverse)
Channel 1: REV
Channel 2: REV
Channel 3: REV
Channel 4: NOR
Channel 5: NOR
Channel 6: NOR
2. -TRAVEL+ (End Points)
Channel 5 (Vector Servo): 125%
All others default: 100%
3. DUAL, EXPO
Personal preference: Set low rates to 60%, –30% exponential
on aileron, elevator, rudder.
4. PROGRAMMABLE MIXER (Vector Mixing)
Note: Sub-trims must be used to trim rudder and vectoring servos.
Switch Position 0 [L] (Rudder + Vectoring)
Switch Position 1 [M] (Rudder Only)
Switch Position 2 [H] Vectoring Only
5. TIMER
3S (2200mAh, 6 x 5 prop): 3-1/2 minutes (adjust accordingly)
4S (2200mAh, 5 x 5 prop): 3 minutes (adjust accordingly)
11
Mix 1
CH4 > CH5 CH4 > CH6
RATE L
+100%
RATE R
+100%
OFFSET
0%
CTRL
SE (Switch E) SE (Switch E)
ON (1)
OFF (0)
ON (1)
Mix 2
+100%
+100%
0%
ON (1)
ON (1)
OFF (0)
