BOARD USE REQUIREMENTS

Cables: The cable you will need depends on the programmer/debugger you use. If you use ARM-
JTAG, you will need LPT cable, if you use ARM-USB-OCD, ARM-USB-OCD-H, ARM-USB-
TINY, or ARM-USB-TINY-H you will need 1.8 meter USB A-B cable, for ARM-USB-OCD and
ARM-USB-OCD-H you will need RS232 cable, too.
Hardware: Programmer/Debugger – one of the Olimex ARM Programmers: ARM-JTAG, ARM-
JTAG-EW, ARM-USB-OCD, ARM-USB-OCD-H, ARM-USB-OCD-TINY, ARM-USB-OCD-H.
Note that Olimex OpenOCD debuggers lack SWD interface by default. There is the adapter ARM-
JTAG-SWD that adds SWD to any of the programmers/debuggers mentioned above.
Additionally you can use our ARM-JTAG-COOCOX debugger which has both JTAG and SWD
interfaces and works with CooCox IDE natively and with IAR EW and Keil uVision via plug-ins.
Note the board can be programmed without a debugger using the serial port (the one with the
DE-9 connector).
Software: ARM C compiler
