Freescale Semiconductor
Reference Manual Addendum
MPC5607B Microcontroller
Reference Manual Addendum
by: Microcontroller Solutions Group
This addendum document describes corrections to the
MPC5607B Microcontroller Reference Manual, order
number MPC5607BRM. For convenience, the addenda
items are grouped by revision. Please check our website
at http://www.freescale.com/powerarchitecture for the
latest updates.
The current version available of the MPC5607B
Microcontroller Reference Manual is Revision 7.1.
© Freescale Semiconductor, Inc., 2012. All rights reserved.
Table of Contents
1
Addendum List for Revision 7.1 . . . . . . . . . . . . . . 2
2
Revision History . . . . . . . . . . . . . . . . . . . . . . . . . 10
MPC5607BRMAD
Rev. 1, 05/2012
