Options
8.2.4

Graphical and Text keypad

There are two keypad types you can choose for your user interface: keypad with graphical display
and keypad with text segment display (text keypad).
The button section of the keypad is identical for both keypad types.
Move backward in menu
Exit edit mode
Reset faults with long press
Move cursor left
Stop button
Local contacts: http://drives.danfoss.com/danfoss-drives/local-contacts/
Scroll menu up
Increase value
Scroll menu down
Decrease value
Enter active level/item
Confirm selection
Figure 59. Keypad buttons.
Change control place
Access control page
Change direction
FUNCT
Move cursor right
Start button
9086.emf
vacon • 81
