vacon • 74
• Connect the supply cable to the Mains switch passing through the cable entry
4
Figure 49. Connection of the supply cable to the Mains switch (right-hand-side example).
• Connect the cables from the Mains switch to the terminal box. The cables have
5
• Place the Mains switch plate with the cables in the groove and fix it with its
6
• Place the cable entry plate with the other cables (motor cable, brake cable, I/O
7
8
plate of the bottom side (use the cable gland for sealing the cable to the gland
plate) and then through the terminal box as shown in the figure below.
to be connected to the terminals L1, L2 and L3.
screws.
cables) in the groove on the bottom side of the drive and fix it with its screws.
Local contacts: http://drives.danfoss.com/danfoss-drives/local-contacts/
Options
