  • Page 1 100x ® vacon 100 ® ac drives marine installation guide...

  • Page 3: About This Manual

    The product fulfills the most common marine certificates. Fig. 1: A Vacon 100 enclosed drive, wall-mounted drive and a Vacon 100 X drive with the marine option 24-HOUR SUPPORT +358 (0)201 212 575 · EMAIL: VACON@VACON.COM...
  • Page 4 VACON · 4 TEL. +358 (0)201 2121 · FAX +358 (0)201 212 205...

  • Page 5: Table Of Contents

    MR10-MR12, and the enclosed drives Installation procedure 4.4.1 Installation of wall-mounted drives in a marine environment 4.4.2 Installation of enclosed drives in a marine environment 5 Commissioning and additional instructions Maintenance 24-HOUR SUPPORT +358 (0)201 212 575 · EMAIL: VACON@VACON.COM...

  • Page 6: Approvals

    APPROVALS APPROVALS These classification societies have granted a marine type approval for this Vacon product. You can find the general approvals in the Installation Manual of your Vacon 100 product. ABS (the American Bureau of Shipping) • BV (Bureau Veritas) •...

  • Page 7: Safety

    WARNING! CAUTION! HOT SURFACE! See the complete list of warnings in the Installation Manual of your Vacon 100 product. NOTE! You can download the English and French product manuals with applicable safety, warning and caution information from http://drives.danfoss.com/knowledge-center/technical-documentation/. REMARQUE Vous pouvez télécharger les versions anglaise et française des manuels produit contenant l'en- semble des informations de sécurité, avertissements et mises en garde applicables sur le site http://...

  • Page 8: Receiving The Delivery

    VACON · 8 RECEIVING THE DELIVERY RECEIVING THE DELIVERY CONTENTS OF THE DELIVERY The contents of the delivery The AC drive and the options that you ordered • An accessories bag • The parts for the marine option • Safety Instructions, and the manuals for the options that you ordered •...

  • Page 9: Lifting The Ac Drive

    Be careful when you lift the enclosed drive to an upright position. If the springs are squeezed for too long, they can become damaged. Also, the springs can bounce suddenly and cause injury to the personnel and/or damage to the equipment. 24-HOUR SUPPORT +358 (0)201 212 575 · EMAIL: VACON@VACON.COM...

  • Page 10: Mounting

    MOUNTING MOUNTING DIMENSIONS OF THE AC DRIVE WITH THE MARINE OPTION Other dimensions can be found in the Installation Manual of your Vacon 100 product. For the dimensions of the Vacon 100 X product, see its Installation Manual. 4.1.1 DIMENSIONS OF THE WALL-MOUNTED DRIVES 4.1.1.1...
  • Page 11 Dimensions of the the wall-mounted drive with the marine option, MR5 214 (8.43) 115 (4.53) 4 x Ø6 17 (0.67) (0.24) 144 (5.67) Fig. 3: Dimensions of the wall-mounted drive with the marine option, MR5, [mm (in)] 24-HOUR SUPPORT +358 (0)201 212 575 · EMAIL: VACON@VACON.COM...
  • Page 12 VACON · 12 MOUNTING 4.1.1.3 Dimensions of the the wall-mounted drive with the marine option, MR6 229 (9.06) 4 x Ø8 148 (5.83) 17 (0.67) (0.31) 195 (7.68) Fig. 4: Dimensions of the wall-mounted drive with the marine option, MR6, [mm (in)]...
  • Page 13 Dimensions of the the wall-mounted drive with the marine option, MR7 259 (10.20) 190 (7.48) 4 x Ø8 17 (0.67) (0.31) 237 (9.33) Fig. 5: Dimensions of the wall-mounted drive with the marine option, MR7, [mm (in)] 24-HOUR SUPPORT +358 (0)201 212 575 · EMAIL: VACON@VACON.COM...
  • Page 14 VACON · 14 MOUNTING 4.1.1.5 Dimensions of the wall-mounted drive with the marine option, MR8 245 (9.65) 390 (15.35) 4 x Ø11 (0.39) (0.20) (0.43) 315 (12.40) Fig. 6: Dimensions of the wall-mounted drive with the marine option, MR8, [mm (in)]...

  • Page 15: Dimensions Of The Enclosed Drives

    Fig. 7: Dimensions of the wall-mounted drive with the marine option, MR9, [mm (in)] 4.1.2 DIMENSIONS OF THE ENCLOSED DRIVES Some options of the enclosed drives require additional cabinets. For more information, see the Vacon 100 Enclosed Drives Installation Manual. 24-HOUR SUPPORT +358 (0)201 212 575 · EMAIL: VACON@VACON.COM...
  • Page 16 VACON · 16 MOUNTING 4.1.2.1 Dimensions of the enclosed drive with the marine option, MR8 781 (30.75) 0 -15 (0.59) (3.39) 446 (17.56) 4 x Ø12 (0.47) 335 (13.19) 13 (0.51) 383 (15.08) 2 x Ø13 (0.51) Fig. 8: Dimensions of the enclosed drive with the marine option, MR8, [mm (in)]...
  • Page 17 781 (30.75) -15 (0.59) (3.39) 646 (25.43) 548 (21.57) 535 (21.06) 4 x Ø12 (0.47) 13 (0.51) Fig. 9: Dimensions of the enclosed drive with the marine option, MR9, [mm (in)] 24-HOUR SUPPORT +358 (0)201 212 575 · EMAIL: VACON@VACON.COM...
  • Page 18 VACON · 18 MOUNTING 4.1.2.3 Dimensions of the enclosed drive with the marine option, MR10 781 (30.75) -15 (0.59) (3.39) 646 (25.43) 535 (21.06) 548 (21.57) 4 x Ø12 (0.47) 13 (0.51) Fig. 10: Dimensions of the enclosed drive with the marine option, MR10, [mm (in)]...
  • Page 19 86 (3.39) 1246 (49.06) 1148 (45.20) 548 (21.57) 548 (21.57) 4 x Ø12 (0.47) 13 (0.51) 1135 (44.69) Fig. 11: Dimensions of the enclosed drive with the marine option, MR12, [mm (in)] 24-HOUR SUPPORT +358 (0)201 212 575 · EMAIL: VACON@VACON.COM...

  • Page 20: Installation Requirements

    Special power distribution zone • General power distribution zone • Passenger accommodation zone • The Vacon 100 drives are not type-approved in bridge or deck zones. 450 V 230 V 230 V 115 V 230 V Fig. 12: The installation zones in a marine environment A.

  • Page 21: The Maximum Vibration

    2-13.2 Hz, amplitude ±1mm • 13.2-100 Hz, acceleration ± 0.7 g • You must also obey the requirements in the Installation Manual of your Vacon 100 product. 4.2.2 INSTALLATION SAFETY IN A MARINE ENVIRONMENT NOTE! We recommend you to install the AC drive with screws, but you can also use welding.

  • Page 22: Installing A Drive In An It Network

    EMC filter. See the Installation Manual of your Vacon 100 product for the disconnection instructions. The disconnection changes the EMC class of the drive to level C4 of the IEC 61800-3 standard.

  • Page 23: Installing A Drive In A Grounded Network: 525-690 V, Enclosure Sizes Mr10-Mr12, And The Enclosed Drives

    10 dB MR12, 690 V Vacon 100 enclosed 10 dB with distance drives 54 dB 55 dB 45 dB or separate electri- cal room * The value decreases logarithmically with frequency. 24-HOUR SUPPORT +358 (0)201 212 575 · EMAIL: VACON@VACON.COM...

  • Page 24: Installation Procedure

    VACON · 24 MOUNTING INSTALLATION PROCEDURE 4.4.1 INSTALLATION OF WALL-MOUNTED DRIVES IN A MARINE ENVIRONMENT INSTALLATION PROCEDURE, MR4-MR9 MR4-MR7: Attach the components of the marine option. Use 4 pcs of Ø 8 mm / 0.31 in screws. Tighten the screw so that it is tight, but so that •...

  • Page 25: Installation Of Enclosed Drives In A Marine Environment

    4.4.2 INSTALLATION OF ENCLOSED DRIVES IN A MARINE ENVIRONMENT INSTALLATION PROCEDURE, MR8-MR12 The bottom dampers are installed at the factory. You must install the upper dampers and plinths on site. 24-HOUR SUPPORT +358 (0)201 212 575 · EMAIL: VACON@VACON.COM...
  • Page 26 VACON · 26 MOUNTING MR8-MR12: Attach the upper damper to the wall. You can use screws or welding. Attach the protection grilles of the cabinet with M5 x 12 mm screws. Attach the handle that you can find in the accessories bag to the holes in the cabinet door with M8 x 40 mm bolts and M8 nuts.
  • Page 27 MR9-MR12: To attach the upper damper, use: A) An M12 x 30 mm bolt tightened to a 60-70 Nm torque B) A 12 mm plain washer C) An M12 nut tightened to a 60-70 Nm torque 24-HOUR SUPPORT +358 (0)201 212 575 · EMAIL: VACON@VACON.COM...

  • Page 28: Commissioning And Additional Instructions

    COMMISSIONING AND ADDITIONAL INSTRUCTIONS COMMISSIONING AND ADDITIONAL INSTRUCTIONS MAINTENANCE See the complete list of maintenance tasks in the Installation Manual of your Vacon 100 product. Table 5: The maintenance intervals and tasks for the marine option Maintenance interval Maintenance task...
  • Page 30 Document ID: Vacon Ltd Member of the Danfoss Group Rev. A Runsorintie 7 65380 Vaasa Sales code: DOC-INS100MA+DLUK Finland...
