SSV Works WP-RZF3O+2F Installation Manual page 2

INSTALLATION INSTRUCTIONS
A. With one person on either side of the vehicle place the WP-
RZF3O+2F into location from the underside of the cage.
C. Once the enclosure is centered side to side, press the bracket
toward the center of the vehicle and tighten the brackets using
the #3 screwdriver. NOTE: After all brackets are tightened,
it may be necessary to go back and re-adjust the brackets to
ensure the enclosure is properly secured.
WIRING INSTRUCTIONS
WP-RZF3O+2F
A
B. While holding the enclosure securely toward the main WP-RZF3O4,
loosely install the 2 brackets using the screws provided.
C
Plug in the 4 pin speaker output from the main unit WP-RZF3O4 into the 4 pin
speaker input on the WP-RZF3O+2F, and then secure to the cage using the
zip ties provided.
NOTE: Increase your sound even more! Add SSV Works #WP-RZF3O+2R for a
total of 8 speakers
© 2016 SSV Works, Oxnard, CA 93030 WP-RZF3O+2F Rev. A 4-12-16
