Pure Fun 9306RS Product Manual page 9

6
10
Do not Install
MODEL# 9306RS
6
6
10
10
8
8
STEP 3:
Parts:
Part 6 (x4) - Seats
6
Part 10 (x12) - Square Nuts
Part 8 (x12) - M6 40mm Bolt
Place the remainder of the Seats at the end
of the Base Rails with the flat surface of the
Seats facing the floor. Place 2x on each side
as shown. Align the side openings to the
corresponding Base Rails opening.
Place the Square Nuts (Part 10) at the end
gaps of the Seat openings, and secure with
a M6 40mm Bolt (Part 8) aligned by the
Base Rail and Seat openings.
NOTE:
When Installing the Seats to the Base Rails,
do not install to the 4 locations circled as
shown. These are reserved to install the
Handle Bars in Step 12.
8
9
