- Page 2 TABLE OF CONTENTS Introduction/Customer Service Information ………………..…. 3 Warranty Information ……………………………………………….……..4 Warnings/Safety Precautions…….………………………………….5-7 Parts List/Hardware……….……………………..……………………….7-8 Assembly Instructions………………………..……………………..…9-11 Maintenance…………………….……………………….…………………..12 Frequently Asked Questions………………………………………..…12...
- Page 3 OWNERS MANUAL CUSTOMER SERVICE INFORMATION Thank you for purchasing our Pure Fun Wavy Slide. ® At Pure Global Brands, Inc., we want all of our customers to be completely satisfied with their purchase. Please take time to review the contents of the product you just received to make sure that all of the parts are included.
- Page 4 (photocopy of the original store receipt, indicating the date of purchase). All freight and handling fees are the responsibility of the consumer to pay, both to and from Pure Fun. All warranty claims must be preauthorized by Pure Fun. Preauthorization can be obtained by calling 866-498-5269. This warranty...
- Page 5 WARNING CHOKING HAZARD – Small parts NOT for children under 3 years. ! Warning! While every attempt is made to ensure the highest degree of protection in all equipment, we cannot guarantee freedom from injury. The user assumes all risks of injury due to use. All merchandise is sold on this condition, which no representative of the company can waive or change.
- Page 6 OWNERS MANUAL PRECAUTIONS/SAFETY INSTRUCTIONS/WARNINGS Dear Customer, Please read this instruction very carefully before using this item. You will find important information regarding safety and your product. IMPORTANT SAFETY INSTRUCTIONS Please read the instructions entirely before use and retain for future reference. This unit must be assembled and disassembled by ADULTS ONLY.
- Page 7 MAINTENANCE TIPS If the paint is chipped, we recommend you lightly rub the damaged area and cover using a non-toxic enamel paint. BEFORE YOU START Please read all instructions carefully. Please dispose of all packing material carefully and keep it away from children. Ensure you have all of the parts listed above.
- Page 8 PARTS LIST...
- Page 9 Step 1 Assemble Ladder and Ladder Base Locate 3x Ladder Steps (H), 2x Handrail Tubes (L), 6x 40mm Bolts (S), 6x Square Washers (U). Insert a square washer into each receptacle in the bottom of the step. Attach each step (H) to the Left and Right Handrail tubes using the bolts.
- Page 10 Step 2 Attach Slide Chute to Ladder Assembly Locate Slide Chute (J) and completed Ladder/Base Assembly. Thread the top of the Handrail Tubes through the holes located in the top of the Slide Chute. Locate 2x 35mm Bolts (B), 2x Washers (D), 2x Spring Washers (E), and 2x Dome nuts (F). Secure the slide chute to the handrail using the above hardware.
- Page 11 Step 4 Assemble the Chute Bottom Support Locate the Chute Bottom Support Tube (P) Attach the Chute Bottom Support Tube (P) to the Tie Bar end (K) using 1x 30mm Bolt (A), 1x Washer (D), 1x Spring Washer (E), and 1 Dome Nut (F). Affix the Slide Chute (J) to the Chute Bottom Support Tube (P) using the holes located on the bottom of the Slide Chute with 2 x 15mm Bolts (T) Step 5...
- Page 12 CARE AND MAINTENANCE Your slide is designed to be very low maintenance. If any part of the slide requires cleaning, simply wipe with a damp cloth. Regularly check to see if slide chute, steel tubes, steps, ground anchors and other parts are tightened and completely secure.
