ASSEMBLY INSTRUCTIONS
2
10
2
11
12
STEP 4:
Parts:
Part 2 (x2) - Foam Rocker Bar
Part 7 (x4) - M6 45mm Bolt
Part 11 (x4) - Hex nut
Part 12 (x4) - Washer
NOTE: Round Cap (Part 16) is already
installed on the Foam Rocker Bar (Part 12).
If not, slide to both ends and make sure the
tub ends are covered
Place the Foam Rocker Bars (Part 2) on the
outside of the Base Rails facing away from
the Seats.
Align the opening of the tip of the Base
Rails to the opening under the Round Cap
of the Foam Rocker Bars.
Tighten with a M6 45mm Bolt (Part 7), Hex
Nut (Part 11), and Washer (Part 12).
7
STEP 5:
Inside the Foam Rocker Bars, there are
8 indent locations as shown. You can find
them when pressed.
Once you have found the indent, using a
sharp Knife, cut a slit in that location to
reveal the opening on the Bar itself.
WARNING!
Cutting the slits on the Foam Rocker Bar
must be done by an adult (+18 Years). For
more information, review The Warning and
Safety instructions on Page 5.
