ASSEMBLY INSTRUCTIONS
5
8
12
11
MODEL# 9306RS
STEP 6:
Parts:
Part 3 (x2) - Handle Tube
Part 5 (x2) - Footrest Tube
Part 8 (x4) - M6 40mm Bolt
3
Part 11 (x4) - Hex Nut
Part 12 (x4) - Washer
Locate the middle openings in the Handle
Tube (Part 3), and align to the openings at
the tips of the Footrest Tube (Part 5).
Tighten with a M6 40mm Bolt (Part 8), Hex
Nut (Part 11), and Washer (Part 12).
Repeat until you have 2x completed Handle
Tubes with the Footrest Tubes installed.
11
