ASSEMBLY INSTRUCTIONS
12
9
12
11
GQBrands.com
STEP 7:
Insert the Assembled Handles on the inside
of the Seesaw.
Align the upper openings of the Handle
Tubes to the Base Rails, and bottom
openings to the Foam Rocker Bars
STEP 8:
Parts:
Part 9 (x4) - M6 50mm Bolt
Part 11 (x4) - Hex nut
Part 12 (x4) - Washer
Locate the aligned middle openings in the
Handle Bar.
Tighten with a M6 50mm Bolt (Part 9), Hex
Nut (Part 11), and Washer (Part 12).
NOTE:
Make sure the head of the Bolts are
facing the outside of the Seesaw to avoid
scratches or scrapes when in use.
