- Page 1 48” SUPER JUMPER KIDS TRAMPOLINE MODEL# 9009SJP PRODUCT MANUAL - VERSION 1.21.01 FOR AGES: WEIGHT LIMIT: TO BUILD: TOOLS NEEDED: 3-10 45 Kgs CUSTOMER SERVICE GQBrands.com • CustomerService@GQBrands.com • 1-866-498 -5269 • 4401 Samuell Blvd, Ste 150, Mesquite, TX 75149...
-
Page 2: Customer Service Information
CUSTOMER SERVICE INFORMATION Thank you for purchasing: 48” SUPER JUMPER KIDS TRAMPOLINE PAINT MODEL# 9009SJP To register you product please visit: www.globalqualitybrands.com/product-registration or scan code: At GQBrands®, we want all of our customers to be completely To order these parts, or if you have any other questions or concerns satisfied with their purchase. - Page 3 • DO NOT fall or bounce on your knees -- the trampoline periodically to ensure the this can cause injury. frame is steady and all parts are in good condition. • DO NOT somersault — this can cause serious injury, including paralysis or death. MODEL# 9009SJP...
-
Page 4: Parts List
PARTS LIST Top Rail T-Joint Leg Cap Not available in this version Jump Mat with Mesh Frame Pad 7R - 7L - Hand Rail Base - Left Hand Rail Base - Right Side Hand Rail Center Hand Rail 10 - 11 - 12 - 13 -... - Page 5 Repeat these steps with all Top Rails and all T-Joints to form the Top Rail Frame. Once the Top Rail Frame has been formed, tighten all hex nuts and place 12x Safety Nut Caps (Part 12) (10) (10) MODEL# 9009SJP...
- Page 6 ASSEMBLY INSTRUCTIONS STEP 2: Slide 1x Hand Rail Base - Left (Part 7L) and slide 1x Leg Cap (Part 4) into a T-Joint to secure it. Then Slide 1x Hand Base Rail - Right (Part LEFT 7R) one leg apart from the Left side as (7L) shown on to a T-Joint, and secure with 1x Leg Cap (Part 4).
- Page 7 (Part 14) in clockwise order from current springs. NOTE: If you see that the Jumping Mat looks uneven, make sure to locate the proper V-Rings on the Mat to the correct Spring to avoid excessive pressure on the Mat. MODEL# 9009SJP...
- Page 8 ASSEMBLY INSTRUCTIONS STEP 6: Place the Frame Pad (Part 6) on top the Jumping Mat. Stretch the Frame Pad so it completely covers all Springs and the Mesh of the Jumping Mat. NOTE: Make sure all springs are completely covered to avoid any injury while in use. GQBrands.com CustomerService@GQBrands.com 1-866-498-5269...
- Page 9 STEP 8: Secure the Center Hand Rail (Part 9) by attaching it to the Side Hand Rails as shown. Secure with the push pin buttons located in the Hand Rails. Make sure this connection is secure before continuing. MODEL# 9009SJP...
-
Page 10: Frequently Asked Questions
FREQUENTLY ASKED QUESTIONS • Question: “One of my trampoline legs has • Question: “I had a part missing from my • Question: “How do I remove the black box” or “something was damaged during caps on the frame of the trampoline?” broken”...
