ASSEMBLY INSTRUCTIONS
1
1
10
8
6
10
8
STEP 1:
Parts:
Part 1 (x2) - Base Rails
Part 6 (x1) - Seat
Place both Base Rails (Part 1) in a flat
surface free of obstructions. Place 1x Seat
(Part 6) with the flat surface facing the floor
and align the side openings to the middle
openings of the Base Rails.
STEP 2:
Parts:
Part 10 (x4) - Square Nuts
Part 8 (x4) - M6 40mm Bolt
Place the Square Nuts (Part 10) at the end
gaps of the Seat openings, and secure with
a M6 40mm Bolt (Part 8) aligned by the
Base Rail and Seat openings.
NOTE:
Push the Bolt all the way until it aligns with
the opening of the Square Nut. Tightening
clockwise will help the Square Nut reach
the end of the Seat gap.
8
