Programmable keys and icons
To make a call, activate a service or manage your calls.
Icons are associated with each of these keys:
Line icons :
Incoming call (flashing).
Call in progress.
Call on hold.
Call on common hold.
Function icons :
Function active.
Function requiring action.
Terminal or line busy.
Preprogrammed function keys:
Divert your calls to another terminal.
Access the various mail services.
Access your personal directory.
Transfer call to another terminal.
Make an ISDN call.
Some other keys have been programmed by your technician for your own conven-
ience:
Key must be programmed by your technician to access a service.
Installing the programmable key label
A printed label is supplied with the terminal. This should be installed beneath the
programmable keys.
1. Insert a flat " blade " into the slot (1 slot
per key block).
2. Raise the cover.
3. Slide the printed label into position.
4. Replace the cover.
Room terminal icons :
1st segment 2nd segment 3rd segment
Room taken Terminal
Lit
Room free
Not lit
Wake-up
alarm
problem
Flashing
Room not
busy
cleaned
Terminal
Room
free
cleaned
Terminal
Room
ringing*
problem
*internal or outside call
