    Paging Station Microphone PGM1 Paging Station Extension PGX1 Installation Manual Installationshandbuch Manuel d’installation Manual de instalación Manual de instalação Manuale all’installazione Руководство по установке 施 工 説 明 書...

  • Page 2

    “OFF” meets FCC requirements. Modifications not and “ON” , please try to eliminate the problem expressly approved by Yamaha may void your by using one of the following measures: authority, granted by the FCC, to use the prod- uct.

  • Page 3: Precautions

    Then have the device inspected or repaired by qualified Yamaha service Do not open personnel. • This device contains no user-serviceable parts. Do not open the device or attempt to...

  • Page 4

    • Avoid pulling the connected cables to prevent injuries or damage to the device by causing it to fall. Yamaha cannot be held responsible for damage caused by improper use or modifications to the device. 4 PGM1/PGX1 Installation Manual...

  • Page 5

    You should note this serial number in the has completely dried out. space provided below and retain this manual as a permanent record of your purchase to aid identification in the event of theft. Model No. Serial No. (bottom_en_01) PGM1/PGX1 Installation Manual...

  • Page 6: Table Of Contents

    • PGX1: Connecting bracket, dedicated screws (8 pcs.), connection cable Firmware update MTX-MRX Editor is used to update the firmware of the PGM1/PGX1 and to check the version. For details on how to perform these operations, refer to “MTX-MRX Editor User Guide.”...

  • Page 7: Introduction

    • Two PGX1 units can be added for each PGM1 unit, allowing you to specify broadcast regions in detail and to select from numerous messages. • You can use MTX-MRX Editor to install up to four PGM1 units in one MTX/MRX system. One of these PGM1 units can be specified as the priority mic.

  • Page 8: Controls And Connectors (pgm1)

    To remove the mic, pull the mic upward be inserted here. You can create labels while pressing an ejector tool (a thin using PGM1 Label Creator which is metal rod of about  2, or a very thin included with MTX-MRX Editor.

  • Page 9: Rear Panel

    UNIT ID; used in conjunction with This specifies the ID by which individual the [UNIT ID] rotary switch described PGM1 units are distinguished within the above which specifies the lower place, MTX/MRX system’s network. In conjunc- you can set the UNIT ID in a range of tion with device setting DIP switches 1–3...

  • Page 10

    Controls and Connectors (PGM1) • Switches 4–5 Not used. Leave these in the factory-set Switch 1 2 3 position (upward). Setting UNIT ID is “2x” • Switch 6 (IP SETTING) The [UNIT ID] rotary switch Specifies how to set the IP address...

  • Page 11: Bottom Panel

    Specify how the unit is initialized after the power turns on. Switch Setting RESUME This is the normal operating mode. When the PGM1’s power is Content turned on, it starts up while preserving the state in which it was immediately prior to pow- ering-off. Switch Setting INT.

  • Page 12: Controls And Connectors (pgx1)

    These buttons select the zone(s) to which This is a dedicated connector for connec- the mic will broadcast, or select mes- tion to the PGM1 or PGX1. sages saved on the SD card. Use MTX- MRX Editor to assign zones or messages to these buttons.

  • Page 13: Initializing The Pgm1

    Initializing the PGM1 If you want to return (initialize) the unit to its factory-set state, for example because the installa- tion location has changed, proceed as follows. Power-off the PSE. Verify that initialization is completed, and then power-off the PSE.

  • Page 14: Connecting The Pgm1 To An Mtx/mrx System

    MTX5-D ID=02 ID=63 About the priority mic Of the PGM1 units connected to an MRX7-D or MTX5-D, one unit can be specified as the pri- ority mic. When the priority mic begins broadcasting, the other mics in the group are muted.

  • Page 15

    Connect a PoE network switch that can work with Dante within the Dante network, and use an Ethernet cable to connect the PGM1 to the network switch. If the network switch does not support PoE, connect a PoE injector between the network switch and the PGM1.

  • Page 16: Connecting A Pgx1

    Turn the PGM1 and PGX1 units over on their back. Place the PGM1 on the right, and place the PGX1 to be connected on the left. Remove the rubber cap from the bottom panel of the PGM1. Use the included connection cable to connect the PGM1 and PGX1.

  • Page 17: Indicator List

    Green (mic being operated) Level Program Output 0 db Chime (SD) Mic Input Mic Output/ SD Input Message (SD) Range -∞ Time Attack Opening Closing Release Chime Chime PTT indicator Green Orange Green (mic not being operated) PGM1/PGX1 Installation Manual...

  • Page 18: Alert List

    / message indicator is set to alert number 1, and the lower right zone / message indicator is set to alert number 8. If the problem cannot be solved, contact your Yamaha dealer listed at the end of this manual. Flashing zone/...

  • Page 19: Specifications

    * Der Inhalt dieser Bedienungsanleitung gilt für die neuesten technischen Daten zum Zeitpunkt der Veröffentli- chung. Um die neueste Version der Anleitung zu erhalten, rufen Sie die Website von Yamaha auf und laden Sie dann die Datei mit der Bedienungsanleitung herunter.

  • Page 20

    European models Purchaser/User Information specified in EN55103-2:2009. Conforms to Environments: E1, E2, E3 and E4 134 PGM1/PGX1 Installation Manual...

  • Page 21: Dimensions

    Dimensions Gooseneck PGM1 microphone Unit: mm PGM1/PGX1 Installation Manual...

  • Page 22

    Dimensions PGX1 Unit: mm 136 PGM1/PGX1 Installation Manual...

  • Page 23

    PGM1/PGX1 Installation Manual...

  • Page 24

    Ce symbole est seulement valable dans l’Union européenne. Si vous souhaitez vous débarrasser de déchets d’équi- pements électriques et électroniques, veuillez contacter les autorités locales ou votre fournisseur et demander la méthode de traitement appropriée. (weee_eu_fr_02) 138 PGM1/PGX1 Installation Manual...

  • Page 25

    Informazioni sullo smaltimento negli altri Paesi al di fuori dell’Unione europea: Questi simboli sono validi solamente nell’Unione Europea; se si desidera scartare questi articoli, si prega di contattare le autorità locali o il rivenditore e richiedere informazioni sulla corretta modalità di smaltimento. (weee_eu_it_02) PGM1/PGX1 Installation Manual...

  • Page 26

    Manual Development Group Yamaha Pro Audio global website © 2017 Yamaha Corporation https://www.yamaha.com/proaudio/ Yamaha Downloads Published 05/2018 POES-C0 https://download.yamaha.com/ VAM5050...
