Yamaha YVC-1000 User Manual

Microphone & speaker system.
Hide thumbs

Advertisement

YVC-1000
Contents
To use a wired handheld microphone
by connecting to YVC-1000 ......................................................1
To use Line 6 XD-V35 by connecting to YVC-1000...........................6
To use Revolabs HD Single/Dual by connecting to YVC-1000 ... 11

Advertisement

   Related Manuals for Yamaha YVC-1000

   Summary of Contents for Yamaha YVC-1000

  • Page 1 YVC-1000 Contents To use a wired handheld microphone by connecting to YVC-1000 ............1 To use Line 6 XD-V35 by connecting to YVC-1000......6 To use Revolabs HD Single/Dual by connecting to YVC-1000 ... 11...
  • Page 2 ■ Operability confirmed handheld microphone  Yamaha: DM-105  Audio-Technica: PRO41  Shure: SM58 * Some models may be unavailable in some areas. Note Handheld microphones which can be directly connected to YVC-1000 are dynamic microphones. Do not use a condenser microphone.
  • Page 3 Connect to a microphone 1. Connect the YVC-1000 audio input terminal (RCA pin) and a handheld microphone with a commercially available audio cable. Before connecting the handheld microphone, turn off YVC-1000. Prepare a proper audio cable for the handheld microphone connecting terminal.
  • Page 4 Use the application software "YVC-1000 Configurator" to change the settings. Memo This manual explains how to change the settings with a PC. Please refer to the YVC-1000 user’s manual when checking difference in operation between a PC and a Mac.
  • Page 5 6. Select "MICROPHONE" in "SIGNAL LEVEL." 7. Test to check sound of the handheld microphone. If there is a problem, change the sound volume and tone with "YVC-1000 Configurator." Note Voice through the handheld microphone is output not only to a communication partner, but also from the YVC-1000 speaker.
  • Page 6 ■ How to change the sound volume and tone On the assumption that the distance between the handheld microphone and your mouth is 3cm, the following values are recommended. Based on these values, change the settings according to your operation environment. ...
  • Page 7 YVC-1000, and use them as external microphones. Voice through the external microphone is output not only to a communication partner, but also from the connected YVC-1000 speaker. With the connected external microphone, you can turn up the voice volume at your site and also have a conversation with the partner.
  • Page 8 "YVC-1000 Configurator" to change the settings. Memo This manual explains how to change the settings with a PC. Please refer to the YVC-1000 user’s manual when checking difference in operation between a PC and a Mac. 1. Download "YVC-1000_Configurator_XXX.zip" from the following website, and decompress the file.
  • Page 9 4. In the "YVC-1000 Configurator" window, select the "AUDIO IN" tab. 5. Set "PA MICROPHONE" in "MODE" of the terminal to which the XD-V35 receiver is connected.
  • Page 10 6. Select "MICROPHONE" in "SIGNAL LEVEL." 7. Test to check sound of the wireless microphone. If there is a problem, change the sound volume and tone with "YVC-1000 Configurator." Note Voice through the wireless microphone is output not only to a communication partner, but also from the YVC-1000 speaker.
  • Page 11 ■ How to change the sound volume and tone On the assumption that the distance between the wireless microphone and your mouth is 3cm, the following values are recommended. Based on these values, change the settings according to your operation environment. ...
  • Page 12 To use Revolabs HD Single/Dual by connecting to YVC-1000 You can connect one unit of Revolabs HD Single/Dual to YVC-1000 and use it as an external microphone. Voice through the external microphone is output not only to a communication partner, but also from the connected YVC-1000 speaker.
  • Page 13 (YVC-MIC1000EX). Also, you can use it in combination with an external speaker. Step 2: How to set To connect Revolabs HD Single/Dual to YVC-1000 for use, you have to change the YVC-1000 settings. Use the application software "YVC-1000 Configurator" to change the settings. Memo This manual explains how to change the settings with a PC.
  • Page 14 4. In the "YVC-1000 Configurator" window, select the "AUDIO IN" tab. 5. Select "PA MICROPHONE" in "MODE". Change the settings of the terminal to which the audio cable is connected.
  • Page 15 Handheld microphone with dedicated adapter: +6dB 8. Test to check sound of the wireless microphone. If there is a problem, change the sound volume and tone with "YVC-1000 Configurator." Note Voice through the wireless microphone is output not only to a communication partner, but also from the YVC-1000 speaker.
  • Page 16 ■ How to change the sound volume and tone Based on the following recommended values, change the settings according to your operation environment. Wearable microphone: On the assumption that the distance between the wireless microphone and your mouth is 10cm, the following values are recommended: ...
