PROGRAMMING MENU
Stop Mode
2H
Stop Time
2I
Adaptive Stop Profile
2J
Adaptive Control Gain
2K
Brake Torque
2L
Brake Time
2M
3 Auto-Start/Stop
Auto-Start Type
3A
Auto-Start Time
3B
Auto-Stop Type
3C
Auto-Stop Time
3D
4 Protection Settings
Excess Start Time
4A
Excess Start Time-2
4B
Undercurrent
4C
Undercurrent Delay
4D
Instantaneous Overcurrent
4E
Instantaneous Overcurrent Delay
4F
Phase Sequence
4G
Current Imbalance
4H
Current Imbalance Delay
4I
Frequency Check
4J
Frequency Variation
4K
Frequency Delay
4L
Restart Delay
4M
Motor Temperature Check
4N
Ground Fault Level
4O
Ground Fault Delay
4P
Reserved
4Q
Reserved
4R
Reserved
4S
Reserved
4T
5 Auto-Reset Trips
Auto-Reset Action
5A
5B Maximum Resets
5C Reset Delay Groups A&B
5D Reset Delay Group C
6 Inputs
Input A Function
6A
Input A Name
6B
Input A Trip
6C
Input A Trip Delay
6D
Input A Initial Delay
6E
Input B Function
6F
Input B Name
6G
Input B Trip
6H
Input B Trip Delay
6I
Input B Initial Delay
6J
Input C Function
6K
Input D Function
6L
42
| User Manual (710-04840-00M)
Coast To Stop
0m:00s
Constant Deceleration
75%
20%
0m:01s
Off
00h:01m
Off
00h:01m
0m:20s
0m:20s
20%
0m:05s
400%
0m:00s
Any Sequence
30%
0m:03s
Start/Run
± 5Hz
0m:01s
10s
Do Not Check
100 mA
0m:03s
-
-
-
-
Do Not Auto-Reset
1
00m:05s
05 m
Motor Set Select
Input Trip
Always Active
0m:00s
0m:00s
Input Trip (N/O)
Input Trip
Always Active
0m:00s
00m:00s
Off
Off
