5. Highlights

MTX-4G-JAVA-IoT Family
EU: LTE 4bands (800, 900, 1800, 2100MHz),
GSM/GPRS/EDGE: 2bands (900, 1800MHz)
US: LTE 4bands (700, 850, 1700, 2100 (AWS),
1900MHz), 3bands UMTS (WCDMA/FDD 850,
1700/2100 (AWS), 1900 MHz)
LTE Cat.1: DL 10.2Mbps, UL 5.2Mbps
4G
HSPA+ Cat.8: data rates DL
3G
7.2Mbps, UL 5.76Mbps
GPRS (EU only): DL 85.6kbps, UL 85.6kbps
2G
CSD
SMS: text and PDU
SMS
mode support
General Features
SIM application toolkit, 3GPP release 99
Control and TCP/IP stacks access via AT
>_
commands
Internet services: TCP, UDP, HTTP, FTP, SMTP,
POP3
Internal 1650mAh Li-Po battery*
+
3-axis accelerometer*
Operating status LEDs
Temperature range: -30º to +85ºC
Dimensions: 78.1x66.8x37.2mm
Weight: <190gr
MTX-Java-IoT | 2018/2
MTX © by MATRIX ELECTRONICA S.L.U.
SUPPORT: iotsupport@mtxm2m.com | SALES: info@mtxm2m.com |
MTX-3G-JAVA-IoT Family
UMTS/HSPA+: 5bands (800, 850, 900, 1900,
2100MHz), GSM/GPRS/EDGE: 4bands (850,
900, 1800, 1900MHz)
HSPA (3GPP release 6,7): DL 7.2Mbps, UL
5.7Mbps; HSDPA Cat.8/HSUPA Cat.6
UMTS (3GPP release 4): PS data
rate 384 kbps DL, UL 384kbps
EGPRS: multislot class 12; EDGE
E2 power class for 8PSK
GPRS class 12; mobile station
class B; PBCCH support
CSD data transmission up to 9.6
kbps, V.110, non-transparent
SMS: point-to-point MO and
MT; text and PDU mode
Interfaces
GSM FME M and SMA F antenna connector
or other RF options*
SIM card interface 1.8V and 3V
DB9 female connector
HD-DB15 female connector: RS232 (4-wire),
3x inputs (2x otpo), 2x opto outputs, 2x
analog inputs
5-way plug-in: RS485, power supply input;
7-way plug-in: latch relay ;
5-way plug-in: 200VAC/6A relay
2x RJ11 connectors*
* Depending on model, see features by model table
