INTRODUCTION

1. Description

The MTX-Java-IoT devices are an innovative and powerful all-in-one solution for the most demanding
M2M and Internet of Things applications, enabling GSM data & voice communication, SMS, fax and
2G/3G/4G high speed cellular data transmission.
The MTX-Java-IoT modems are Java J2ME programmable and have a complete set of interfaces (RS232,
RS485, USB, I2C, optoisolated IOs and Analog-to-Digital converter) avoiding need for further hardware
components, shortening time to market and reducing costs. It also has a modular architecture allowing
a series of optional features:
• GPS module inside: allows track & location applications
• RF card: up to 2x wireless modules (Wavenis, Bluetooth, ZigBee, ISM 868/915, LORA, Sigfox,...)
• Internal Li-Po Battery
• Ultra Low Power: 2.5µA power consumption in sleep mode. Ideal in remote-battery operated
systems
• Relay: latch relay or 220VAC/6A relay options are available
• Analog audio: enabling voice applications
Please read section Introduction 3 (Features by Model) to view the specific features of each device.
The MTX-Java-IoT family is industrially featured: the unit can be used in industrial environments due to its
extended operating temperature range. It also features an automatic restart after shutdown function in
case of power glitches or faulty conditions.
The MTX-Java-IoT are a self-contained modems with its own SIM card holder, USB 2.0 High Speed and
RS232/485 interfaces (among others), which minimize the need for further hardware development. This
device can be used as a powerful and flexible device that can be integrated in a wide range of telemetry
applications that rely on the remote exchange of data, SMS or faxes via the GSM cellular network.
The five-band functionality allows for operation in all relevant GSM frequencies across the world. Local
European and America economic variants are available. When UMTS/3G network operation is not
present, the MTX-Java-IoT can operate in lower speed modes such EDGE Class 12 (max. 237kbps DL,
max. 237kbps UL) or GPRS Class 12 (max. 85.6kbps DL, max. 85.6kbps).
The MTX-Java-IoT devices can also be controlled via AT commands and standard interfaces such us USB
2.0 High Speed or RS232 with Linux and Windows® drivers.
The MTX-Java-IoT family is RoHS & WEEE compliant and it is manufactured following the ISO 9001 & IS0
14001 Quality certifications.
A full list of antennas, cables and accessory supplies are available.
The MTX-Java-IoT modems are powered by an internal EHS6/8/BGS5/ELS6/5 modules.
