1.5 Highlights

Interfaces
•
GSM FME M antenna connector
•
SMA F antenna connector for GPS or other RF options (*)
•
USB 2.0 High Speed port up to 480Mbps
•
SIM card interface 1.8V and 3V
•
Operating status LEDs
•
DB9 female connector: complete 8-wire RS232 modem interface (*)
•
DB15 HD female connector:
o 1x RS232 (4-wire) port (*)
o 2x optoisolated inputs
o 2x optoisolated outputs
o 1x count input
o 2x analog inputs
•
5-way plug-in 5.00mm pitch terminal block (STD models):
o 1x RS485 interface
o Power supply input
•
7-way plug-in 3.5mm pitch terminal block (CAN models):
o 1x CAN bus
o 1x 1-Wire bus
o 1x Latch Relay (2 contacts)
o Power supply input
•
5-way plug-in 5.00mm pitch terminal block (RAC models):
o 1x RS485 interface
o Power supply input
•
2x RJ11 connectors (AUDIO models)
o Analog audio
o Power supply input
General features
•
World Wide Version (default)
o UMTS/HSPA+: Five-Band 800/850/900/1900/2100MHz
o GSM/GPRS/EDGE: Quad band 850/900/1800/1900MHz
•
3GPP Release 6, 7
•
SIM Application Toolkit, 3GPP release 99
•
Control via AT commands (Hayes, TS 27.007, TS 27.005)
•
TCP/IP stack access via AT commands
•
Internet services: TCP, UDP, HTTP, FTP, SMTP, POP3
•
Operating temperature range: -30ºC to +85ºC
•
Dimensions, excluding connectors: 78.1 x 66.8 x 37.2mm
•
Weight: < 190 g
•
IP30 enclosure
•
Internal 1650mAh Li-Po battery (*)
